Husqvarna T425 (2008) parts [19/27] Page j t425

Page J T425 CASE COMP

Position Article Quantity Description Kit

1 505 04 39-01 1 CASE COMP

2 505 04 40-01 2 SCREW 1

3 505 04 68-01 4 SCREW

4 505 04 57-01 1 COVER, FRONT

5 505 04 70-01 2 SCREW

6 505 04 41-01 1 PIPE ASSY

7 505 04 42-01 1 PIPE 6

8 505 04 43-01 1 GROMMET 6

9 505 04 44-01 1 FILTER 6

10 505 04 45-01 1 COLLAR 6

11 505 04 53-01 1 BREATHER

12 505 04 54-01 1 GROMMET

13 505 04 58-01 1 PUMP

14 505 04 59-01 1 PIPE

15 505 04 60-01 1 FUELCAP ASSY

16 505 04 61-01 2 GASKET 16, 35

17 505 04 69-01 1 COVER

18 505 04 70-01 1 SCREW

19 505 04 71-01 1 MAT

20 505 05 89-01 1 DECAL. WARNING SIGNS

21 505 04 66-01 1 CATCHER

22 505 04 67-01 1 SCREW

23 505 04 64-01 1 PLATE

24 505 04 65-01 1 SEAL 23

25 505 04 55-01 1 VALVE

26 505 04 56-01 1 SEAL

27 505 04 75-01 1 DAMPER

28 505 04 95-01 1 BOLT

29 505 04 96-01 1 CAP

30 505 04 72-01 1 SCREW

31 505 05 92-01 1 EYELET

32 505 04 70-01 2 SCREW

33 505 15 21 01 1 EYELET

34 505 05 23-01 1 SCREW

35 505 04 62-01 1 OILCAP ASSY,
