ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 22
Dotz TPar System Fuse Replacement
Dotz TPar System Cleaning
Due to fog residue, smoke, and dust cleaning the internal and exter-
nal optical lenses must be carried out periodically to optimize light
output.
1. Use a soft cloth to wipe down the outside casing.
Cleaning frequency depends on the environment in which the fixture
operates (i.e. smoke, fog residue, dust, dew).
Listed below are a few common problems the user may encounter,
with solutions.
Unit not responding to DMX:
1. Check that the DMX cables are connected properly and are
wired correctly (pin 3 is “hot”; on some other DMX devices
pin 2 may be ‘hot’). Also, check that all cables are connected
to the right connectors; it does matter which way the inputs
and outputs are connected.
Unit does not respond to sound:
1. Quiet or high pitched sounds will not activate the unit.
If problems are not resolved; Contact ADJ Products, LLC for service.
1-800-322-6337
Dotz TPar System Troubleshooting
Locate and remove the unit’s power cord. Once the cord has been
removed located the fuse holder located inside the power socket.
Insert a flat-head screw driver into the power socket and gently pry out
the fuse holder. Remove the bad fuse and replace with a new one. The
fuse holder has a built-in socket for a spare fuse be sure not to confuse
the spare fuse with active fuse.
Dotz TPar System Alternate Lighting Installation
A special feature that this system has is that you are able to mount
two light eects on top of the “T” bar. You are then able to power
those lights by plugging the power cords directly into the bar. The
power sockets are located on the right side and left side. The middle
power socket is for power cord daisy chaining. Do not use the
middle power socket to power your added lights.
To add the lights onto the top is a simple process. Make sure your “T”
bar is set up on the stand correctly and is secure. Follow the instruc-
tions below.
1. Start by unscrewing the black knob that is attached to the bolt.
2. Attach the lighting eect to the bolt using the lighting eects con-
nected bracket.
3. After you have set the bracket onto the bolt, screw the black knob
and secure the knob tightly. See the sample pictures below.
4. Plug the mounted lights into their respective power jacks.
