ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 3
• 4 x COB LED Par Wash Fixtures
1 x Foot Controller
1 x Lighting Stand
1 x RF Remote Control
1 x Stand Bag
1 x Soft Case for Lighting System
• RGB Color Mixing
• Strobing
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• Five DMX Modes: 3 Channel Mode, 5 Channel Mode, 9 Channel
Mode, 12 Channel Mode, & 18 Channel Mode
• 4 Operating Modes - Sound Active, Auto Run, Built-In Programs,
or DMX Control
• Power Cord Daisy Chaining (See Page 21)
Dotz TPar System Warranty Registration
The Dotz TPar System carries a 2 year (730 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase
and warranty. You may also register your product online at www.
americandj.com. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return authorization
(R.A.) number. If the unit is under warranty you must provide a copy
of your proof of purchase invoice. Please contact ADJ Products, LLC
customer support for a R.A. number.
Dotz TPar System Features
To optimize the performance of this product, please read these operat-
ing instructions carefully to familiarize yourself with the basic operations
of this unit. These instructions contain important safety information
regarding the use and maintenance of this unit. Please keep this manual
with the unit, for future reference.
Dotz TPar System General Instructions
Dotz TPar System Introduction
ADJ Products, LLC - www.adj.com - Dotz TPar System User Manual Page 2
Unpacking: Thank you for purchasing the Dotz TPar System by ADJ
Products, LLC. Every Dotz TPar System has been thoroughly tested
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your x-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without rst
contacting customer support.
Introduction: The Dotz TPar System is part of ADJ’s continuing pur-
suit for creating high quality affordable intelligent fixtures. The Dotz
TPar System is a high performance, DMX intelligent, moving head LED
fixture. This fixture is a great piece for retail stores, displays, mood,
architectural, interior and exterior decoration, and clubs. This unit can
be used as a stand alone, or in a Master/Slave conguration. The unit
can also be controlled via DMX controller. This fixture is suitable for
theaters, studios, retail stores, and other similar locations.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide set up help and to answer any question
should you encounter problems during your set up or initial operation.
You may also visit us on the web at www.adj.com for any comments
or suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
