Toshiba TS218 [30/32] Remote control
![Toshiba TS218 [30/32] Remote control](/views2/2016785/page30/bg1e.png)
14
Specications
Model Name TS218
Soundbar
Power Supply AC100-240V~ 50/60Hz
Power Consumption 30W
Standby Power < 0.5 W
USB port for playback
USB Compatibility
USB Playback support / le formats
5V
500mA
Hi-Speed USB (2.0) / FAT32
32G (max) , MP3/WAV/WMA
Dimension (WxHxD) 960mm x 58mm x 82mm
Net weight 2.0 kg
Audio input sensitivity 500mV
Frequency Response 120Hz - 20KHz
Wireless Specication
Bluetooth Version V 4.2
Bluetooth Maximum power transmitted 5 dBm
Frequency bands 2402 MHz ~ 2480 MHz
2.4G wireless maximum power transmitted 6 dBm
2.4G wireless frequency bands 2400 MHz ~ 2483 MHz
Subwoofer
Power Supply AC100-240V~ 50/60Hz
Power Consumption 30W
Standby Power < 0.5 W
Dimension (WxHxD) 170mm x 342mm x 313mm
Net weight 5.5 kg
Frequency Response 40Hz - 120Hz
Amplier (Outputpower)
Sound bar 120W, 30W x 4 (@10%THD)
Subwoofer 80W (@10%THD)
Total 200W
Remote Control
Distance/Angle 6m / 30°
Battery type 2×LR03,1.5V, AAA
