PCDVRR440GPS
12
© Prestigio Plaza Limited
EN General Information
Specifications
Display: 3", IPS, 640×360. Sensor
: 1/2.8
", Sony Starvis 307 (2
MP). Viewing angle:
136°
. Diaphragm: 1.
8
. Video resolution: Full
HD 1920×1080 at
60
fps.
Maximum frame rate: 60 fps. Recording mode: cyclic (1/3/5 min). Video codec: H.264. Digital video recording format: TS. Photo resolution: 2
MP. Number
of lenses: 6. Number of IR filters: 1. Internal memory: 16 MB. Supports memory cards: microSD (SDHC/SDXC) up to 128 GB
. Processor: NTK96675. GPS
module: built-
in. Warm start: no more than 1 minute. Cold start: no more than 5 minutes. CPL filter: removable. Video camera database: yes.
Wi-Fi: IEЕE 802.11 b/g/n (2.4 GHz). Wi-Fi module emission power: 13~17 dBm. Wi-Fi power consumption: 190 mW (standby mode), 650
mW
(operating mode). Motion sensor: yes. Night scene mode: yes. Electronic image stabilization: no. G-sensor: yes. Speaker: built-in. Microphone: built-
in.
Power supply: car power adapter (input: 12–24 V (DC), output: 5 V / 2.0 A (2.4 A for Apple devices) (DC); 2 connectors). Supercapacitor (non
-
removable): 2×2.7 V, 3.3 F. Supercapacitor lifespan: 1 MM cycles, or 30,000 h. Overvolt
age protection: yes. Operating conditions: temperature
−20...+70 °C, relative humidity 15–65% (without condensation). Storage conditions: temperature −30...+80 °C, relative humidity 15–
65%. Colour:
black. Body material: ABS plastic + tempered glass. Mounti
ng type: magnetic holder on suction cup. Size (L×W×H): 9
7
×56.
7
×
35
mm. Weight: 1
05.5
g
Functions
Compact device PCDVRR440GPS combines the functions of video recorder and GPS
-
informer with a database of coordinates of the main points of
road
control. GPS-receiver determines the coordinates of the nearest control point and, according to the current database, displays information a
bout
the permitted speed and additional types of control. The device is also equipped with a Wi
-
Fi module for connection to a mobil
e device
Scope of supply
Video recorder
PCDVRR440GPS
with built
-
in GPS
-
module, a magnetic suction cup holder with a USB Type
-
C connector, car power adapter
(2 output connectors USB Type-A), cable USB Type-C (cable length 3.6 m), CPL filter, accessories fo
r cable installation, card reader, cloth for screen
cleaning, textile case, quick start guide, warranty card
Warranty
2
year
s
Service life
2
year
s
Operating instructions
Memory card installation
While observing the correct orientation of the microSD card (not included), insert it into the video recorder with the external power turned off. Press until you hear a click.
Video recorder installation
1. Choose a place to mount the video recorder.
2. Insert the magnetic suction-cup holder into the mounting slot.
3. Remove the protective film from the sticky surface of the suction cup holder.
4. Loosen the mechanism holding the suction cup. Install the suction cup and clamp the mechanism.
5. Connect the car charger cable (included) to the USB Type-C power connector of the video recorder.
6. Connect the charger to a vehicle power source (cigarette lighter socket in the car).
To permanently place the video recorder in one place, use the 3M tape mount.
Video recorder operation
When you start the engine of the car, the video recorder will automatically start cyclic recording of video files of 1/3/5 min duration (the duration is set by the user
in the settings of the device). At the same time, the status LED indicator of the device will turn blue. When the engine turns off, the video recorder will save the last
video file and stop working. Also, if you press the power button for a long time, it is possible to turn on/off the video recorder manually (with external power on).
