8
ENGLISH
will appear on the display (13) (fig. 3), the vacuum cleaner
will switch to the wet cleaning mode; the LED lights (17)
will also turn on at this time. The water spray indicator (16)
and LED light (17) will not be turned off while the vacuum
cleaner is in motion, even if you release the button (10).
The vacuum cleaner will cease to operate as soon as you
release the water spray button (10) and stop moving the
vacuum cleaner for more than 3 seconds. Take note of the
display (13) during cleaning – the display (13) will show the
charge level of the battery (14).
NOTE: before washing the floors, it is best to dry-clean
them with the vacuum cleaner, then activate the water
scatter function to scatter the water and clear the floor.
Doing so will produce better cleaning results.
Filling the water tank
Open the water tank (11) cover (fig. 5) and fill it with water
using the measuring cup (5). The water tank (11) capacity
is around 400 ml. Do not exceed the top marking level when
filling the water tank (11) with water.
Charging batteries
1.
Attach the holder to the wall, using the screw (12),
then secure the handle (6) on the holder, position the
vacuum cleaner at an angle (fig. 6), and plug the char-
ger (7) (fig. 7) into the body (4).
2.
Plug the power supply unit into an electrical socket
(fig. 7) – the display will show the current charge level
of the battery (fig. 3).
NOTE: the unit will not switch on while charging.
CLEANING AND MAINTENANCE
1.
To remove the dust box (1), disconnect it from the
brush (3) (fig. 8). To open the dust box (1) cover, press
the button on the cover (fig. 8), and take out the gar-
bage. Wash the dust box (1) with water and let it dry.
2.
To remove the filter (2) module, take the handle, pull it
out, and carefully shake off the dust. Rinse the filter (2)
module with water and let it dry.
3.
Remove the mop pad (8) attachment from the floor
brush (3), wash it and let it dry before next use (fig. 9).
4.
Once the dust box (1) has been cleaned, first reinstall
the filter (2) into the dust box (1), then reinstall the dust
box (1) into the floor brush (3), and reattach the mop
pad (8) to the floor brush (3) (fig. 10).
DELIVERY SET
Vacuum cleaner – 1 pc.
Power supply unit – 1 pc.
Mop pad attachment – 1 pc.
Beaker – 1 pc.
Instruction manual – 1 pc.
Warranty certificate – 1 pc.
TECHNICAL SPECIFICATIONS
Vacuum Cleaner
Power supply: 10.8 V , rechargeable
battery - Li-Ion 10.8 V 2000 mAh 21,6 Wh
Rated input power: 85 W
Input voltage: 18 V 0.5 A
Suction power: up to 4.5 kPa
Battery charging time: 4-6 hours
Power Supply Unit
Power supply: 100-240 V ~ 50/60 Hz 0.3 A
Output voltage: 18 V 500 mA
Class II
RECYCLING
For environment protection do not throw out the unit
and the batteries (if included), do not discard the unit
and the batteries with usual household waste after the
service life expiration; apply to specialized centers for
further recycling.
The waste generated during the disposal of the unit is
subject to mandatory collection and consequent dis-
posal in the prescribed manner.
For further information about recycling of this prod-
uct apply to a local municipal administration, a dis-
posal service or to the shop where you purchased
this product.
The manufacturer preserves the right to change design,
structure and specifications not affecting general prin-
ciples of the unit operation without a preliminary notifi-
cation due to which insignificant differences between
the manual and product may be observed. If the user
reveals such differences, please report them via e-mail
info@coolfort.ru for receipt of an updated manual.
Unit operating life is not less than 3 years
Guarantee
Details regarding guarantee conditions can be obtained
from the dealer from whom the appliance was purchased.
The bill of sale or receipt must be produced when making
any claim under the terms of this guarantee.
This product conforms to the EMC Directive
2014/30/EU and to the Low Voltage Directive
2014/35/EU.
