Huion KD200 Black [13/37] Click customize in the picture above to pop up a quick menu see picture 1 for each of the six buttons on the left users can enter a name for it and set its unique function af...

KD200

Run Program Click Browse and select the program that you want to run quickly. After that, press the key to launch the item.

System Application You can apply these functions to press keys: Lock the Screen, Sleep, Power Off,

Multimedia You can apply these functions to press keys: Previous Song, Next Song, Play/Pause,Volume up, Volume down, and Muted.

Precision Mode You can toggle between normal precision and a precision that you choose, from Fine to Ultra Fine. In the Precision Mode window that

appears, move the slider to set the precision that you toggle into. For example, if you assign Precision Mode to a pen button, when you

press the pen button, you switch to working in the precision that you selected from the slider. When you press the pen button again,

you switch back to working in the normal precision. Press “Esc” to exit Precision Mode.

Pan/Scroll This function allows you to pan and scroll in a document or item by moving the pen tip up and down or right and left.When you select

Pan/Scroll, the Scroll Speed window appears. Move the slider to your preferred scrolling speed.

Quick Menu Pick it up and you can use the key to pull up the Quick Menu. Detailed information for reference is down below this table.

Fixed Pressure

Sensitivity

You can lock the pressure at the current level until you release the component. For example, if you assign this setting to a pen button,

you can paint with pressure sensitivity enabled in your application until you reach the brush size you like. Then, press and hold the pen

button to lock in that brush size as long as you are pressing and holding the button.

None When select None, the keys will have no function.

Click Customize in the picture above to pop up a quick menu (see picture 1). For each of

the six buttons on the left, users can enter a name for it and set its unique function.

After that, users can call up the Quick Menu by pressing the key (see picture 2). The

menu disappears after a click on any of the six buttons. By clicking “Fix” once the menu

will be fixed on the desktop while after a second try the “Fix” button changes to “Close”

and the menu disappears (see picture 3). Put the cursor on the menu to drag it.

13 / 37
