Huion KD200 Black [34/37] Pen nib replacement
![Huion KD200 Black [34/37] Pen nib replacement](/views2/2029000/page34/bg22.png)
KD200
Use the side buttons
The buttons on the pen can be set to two different customizable functions.
You can use the buttons whenever the pen tip is within 10mm of the tablet active area.
You do not have to touch the pen tip to the tablet in order to use the switch.
Pen Nib Replacement
The nib will be wear off after using for a long time, then you need to replace a new nib.
1. Anticlockwise rotate the pen holder to open the cover, take a new nib out.
2. Insert the pen nib into the pen nib clip and tilt the pen to pull out the old nib.
3. Insert the new nib straight into the pen and push the nib slowly and firmly until it stops.
34 / 37
