KD200
[2] Screen Ratio: The ratio of the active pen tablet area depends on that of the display device,
which as a general rule, is 16:9. In Screen Ratio mode, these two ratios keep the same.
[3] Custom Area:
1> Enter coordinate values.
2> Users can adjust the working area of the pen tablet by changing the outlines of the smaller
rectangle (see picture 1). Users can also drag the two blue rectangles to select the active areas
of the digital pen on the screen and the pen tablet. (see picture 2 and 3).
15 / 37
