Instruction Manual
Specifications and functions are subject to change by the manufacturer without notice due to
continuous improvement of this product.
MANUFACTURED AND DISTRIBUTED BY TECHNO ELECTRIC LIMITED,
Legal address:
Frequency response
Weighted signal-to-noise ratio
Harmonic distortion
Subsonic filter adjustment range
LPF adjustment range
120 W х 2
10 Hz ~ 30 kHz
96 dB
0.05%
0/6/12 dB
—
50 ~ 250 Hz
Input sensitivity
0.2 ~ 5V
RF frequency adjustment range
120 Hz - 3 kHz
Fuse
1 x 25 A
Unit dimensions (L x H x W) mm
174 х 52 х 209
What's in the box
1 pc.
1 pc.
Car amplifier
Instruction manual
Specifications
Rated output power at 4 ohms
at 2 ohms
bridge mode at 1 ohm
Peak output power
180 W х 2
360 W х 2
800 W
Switchable bass boost control
(Bass boost)
6
• You do not need to set up
the amplifier input connection before
connecting the speaker outputs.
Speaker output connections
• Connect the right and left
speaker wires to the corresponding
speaker output terminals on the
amplifier.
• First, set the volume
control on the amplifier to min. After turning on
the radio for the first time, set the volume
control of the radio to about 80% of full power.
Start playing the sound and slowly turn up the
volume of the amp until you hear distortion,
then turn the volume down for a cleaner
sound.
Volume control
wire from the speaker is connected to the
positive terminal of the amplifier and the
negative wire to the negative terminal.
Reversing either of these connections will
move the speaker cones out of phase,
resulting in bass suppression.
• Make sure the positive
