Candy CEHDD30TCT/1 [6/24] Locking the controls
![Candy CEHDD30TCT/1 [6/24] Locking the controls](/views2/2032703/page6/bg6.png)
EN-9
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
Using your Ceramic Hob
To start cooking
1. Touch the ON/OFF control.
After power on, the buzzer beeps once, all displays show
“ – “ or “ – – “, indicating that the induction hob has entered
the state of standby mode.
2. Place a suitable pan on the cooking zone that
you wish to use.
• Make sure the bottom of the pan and the surface
Of the cooking zone are clean and dry.
3. Touching the heating zone selection control, and
a indicator next to the key will flash.
4. Set a power level by touching the “-” or “+” control.
• If you don’t choose a heat setting within 1
minute, the ceramic hob will automatically
switch off. You will need to start again at step 1.
• You can modify the heat setting at any time
during cooking.
5. When zone 1 is working, touch the heating zone selection
control then activate double zone by pressing .
When double zone is working, touch the heating zone selection control then
turning off the double zone by pressing .
EN-10
When you have finished cooking
1. Touching the heating zone selection control that you
wish to switch off.
2. Turn the cooking zone off by touching the “-” and scrolling down to “0”, or
holding the “+” and “-” button at the same time for 1 second, it will cut down to ”0”
directly.
Make sure the power display shows “0”, then shows “H”.
and then
3. Turn the whole cooktop off by touching the “ON/OFF” control.
4. Beware of hot surfaces
“H” will show which cooking zone is hot to touch. It will disappear when the
surface has cooled down to a safe temperature. It can also be used as an energy
saving function if you want to heat further pans, use the hotplate that is still hot.
Locking the Controls
• You can lock the controls to prevent unintended use (for example children
accidentally turning the cooking zones on).
• When the controls are locked, all the controls except the ON/OFF control are
disabled.
To lock the controls
Touch and hold the keylock control for a while. The timer indicator will show “Lo”.
To unlock the controls
1. Make sure the ceramic hob is turned on.
2. Touch and hold the keylock control for a while.
3. You can now start using your ceramic hob.
When the hob is in the lock mode, all the controls are disable except the
ON/OFF , you can always turn the ceramic hob off with the ON/OFF
control in an emergency, but you shall unlock the hob first in the next
Operation
