Тион 4S Family [11/36] Troubleshooting

Тион 4S Base 00-10027942 [11/36] Troubleshooting
Troubleshooting
If the device isn't working, please check the display and try one of the following
The device is not connected to a power supply
The socket is not providing power
Power board malfunction
Control system error
The current environment does not meet the device's operational requirements
The temperature of electronic components exceeds the acceptable range
Power spike detected, device is in protective mode
Critical error
1 Connect the device to a power supply
2 Make sure the power supply is working correctly (connect a device that you know
is functional)
3 Unplug the device and contact the Service Center
1 Unplug the device for 10–15 seconds
2 Wait for the environment to normalize (when the intake temperature falls within
the acceptable temperature range)
3 Unplug the device for 10–15 seconds. If the error persists, write down the
warning code (shown on the URC display or the mobile apps). When contacting
the Service Center, please have the following information available: device serial
number, personal information to register your claim, device mounting method
(wall type, internal and exterior wall details, other items mounted and their type).
1 Unplug the device for 10–15 seconds
2 Write down the error code (shown on the URC display or the mobile apps)
Unplug the device for 10–15 seconds
3 If the error persists (or a new warning appears), please have the serial number
and your personal information ready in order to contact the Service Center
4S ECO
Specifications
Parameter1 Tion Breezer 4S 4S EU
Acceptable intake temperature range, °С
Nominal wattage, W
Heater wattage, W
Source voltage, V/Hz
Maximum output², m³ph
Maximum noise level, dBA
Net mass³, kg
Dimensions, mm
-40…+50
1050
1000
230 / 50
140
47
8,2
528×453×203
-25…+50
850
800
—
—
—
8,2
—
0…+50
50
—
—
—
—
7,5
—
1 The specifications listed are only guaranteed provided that the device is used with the Tion air
intake grille installed on the vent duct on the outside, and that the instructions for air duct
preparation and device mounting have been followed correctly.
2 Achieved with minimal required filter set: G4 + EPA E11.
3 Device mass, no filters.
Safety
Failure to comply with these requirements may result in
device breakage and/or health and safety hazards.
The device should not be used by children or anyone with certain physical, sensory or
mental impairments without supervision.
Keep the power cord out of the reach of children and pets, even when the device is off.
Keep all packaging materials (cardboard, plastic bags, etc.) out of the reach of children and
pets.
Do not carry out any repairs or alterations to the design of the device. If any damage or
possible signs of malfunction are detected, contact the Vendor's service center for advice
on further operation of the device.
Do not activate the device if the power supply cord insulation or any part of the housing is
damaged.
Unplug the device before conducting any maintenance.
11
EN
