14 / EN
Cooker Hood / User Manual
5.4 Drilling mounting holes
• Adhere the installation template provi-
ded with the appliance onto the surface
on which the installation will be carried
out.
• Drill the holes indicated on the installa-
tion draft with A, B, C, D using a Ø4 mm
drill bit. (Figure 1)
Figure 2
• Cut the lower surface of the cabinet
where the hood will be installed in the
dimensions specified in the technical
drawing (Figure 2).
1
2
3
Figure 3
1. 3.5x9.5 screw
2. Ø 120 mm plastic flue
3. BodyValve pin socket
• Attach the plastic flue contained in the
package to the body of the appliance
using 2 screws 3.5x9.5. Do not rub it
against the surface. (Figure 3)
Figure 4
1. Air discharge pipe
2. Air exhaust flue of the hood
• Attach the air discharge pipe to the air
exhaust flue and fasten via clamp (Fi-
gure 4).
A
CAUTION: As the bends and
elbows in the aluminum pipe
will cause decrease in the air
suction power, using these
must be avoided as much as
possible.
1
2
Figure 5
1. Kitchen cabinet bottom view
2. 4x3,9x32 hood installation screw
• Place the hood into the kitchen cabinet
and attach the hood to 4 installation
holes drilled before (Figure 5).
5.5 Storage
• If you do not intend to use the appli-
ance for a long time, please store it
carefully.
5
Setting up the device
