5
ENGLISH
Button Description
(30) «LIGHT»
The button is intended to switch the indoor unit display (5) panel illumination on and off,
remote control display symbol -
(31) «SLEEP»
Used to set or cancel sleep mode.
Auto restart will be activated when this button is pressed more than 10 times within 8 seconds
in cooling or heating mode. Remote control display symbol -
INSTRUCTION MANUAL
The air conditioner operates through automatic opera-
tion mode selection (HEATING, DEHUMIDIFICATION,
VENTILATION, COOLING), depending on the room tem-
perature at launch.
CONTROLS
– After connecting the air conditioner to the mains, press
the «ON/OFF», button (22) to switch it on. A symbol (41)
representing the current state will appear on the display.
– Select the cooling « » or heating « » mode with the
«MODE» button (23).
– Use the « » and « » buttons (25), (24) to set the nec-
essary temperature from 16 to 30 °С.
Note: While in the «AUTO» mode, the temperature is set
automatically and cannot be changed manually.
– Use the «FAN» button (26) to set the necessary fan
airflow speed: «AUTO» - automatic, « » - low, « » -
medium, « » - high speed.
– Use the « » button (27) to set the vertical louvre (6)
operation mode.
– Press the respective buttons to enable the SLEEP,
TIMER, TURBO, LIGHT, functions.
Switching the air conditioner off
in the automatic mode
– While in the automatic mode, depending on the room
temperature, the air conditioner will operate either in
the cooling or in the heating mode to make the user
comfortable.
– Press the «ON /OFF» button (22) on the remote control
(10) - the display will show a symbol, indication that the air
conditioner is operating either in the heating « » (36) or
in the cooling « » (33) mode. Select the automatic mode
by tapping the «MODE» button (23), symbol « » (32).
Note: If the remote control is malfunctioning, you can
switch the air conditioner off in the automatic mode, us-
ing the emergency control button (21). Press and hold the
emergency button (21) on the internal unit.
The operation mode and temperature are contingent
on the room temperature.
Room
temperature
Operation mode Eventual
(scheduled)
temperature
below 20 °C Heating 23 °C
20 °C - 26 °C Dehumidification 18 °C
above 26 °C Cooling 23 °C
Note: During subsequent uses, the automatic mode can
only be enabled by pressing the «ON /OFF» button (22).
Temperature setting
Press the «ON /OFF» button (22) on the remote control
(10) - the display will show a symbol, indication that the air
conditioner is operating either in the heating « » (36)
or in the cooling « » (33) mode. Select the necessary
operation mode by tapping the «MODE» button (23). Use
the « » and « » buttons (25), (24) to select the necess-
sary temperature.
TIMER mode
The timer mode is best enabled when leaving the house, so
that the comfortable room temperature has been reached
by the time you return home. You can also set the timer for
the night to sleep well.
– when the remote control is off, press the TIMER button
(28) to set the time interval to switch the air conditioner
on, or press the button again, to cancel the setting.
– when the remote control is on, press the TIMER button
(28) to set the time interval to switch the air conditioner
off, or press the button again, to cancel the setting.
Pressing the (TIMER) button (28) will make the respective
symbols (43, 44) appear on the remote control display,
then, using the « » and « » buttons (25), (24), set the
necessary time interval (timer step - 30 minutes).
To cancel the timer settings, press the TIMER button (28)
twice and the settings will be canceled.
Note: After setting the timer, make sure that the « »
indicator (18) of the internal unit is on.
HEATING mode specifics
Preheating
While in the heating mode, the airflow from the internal unit
begins to blow out in 2-5 minutes.
Subsequent heating
After switching the mode off, the airflow from the internal
unit ceases within 2-5 minutes.
Defrosting of the internal unit
If the room and outside temperature is low, the heat
exchanger of internal unit begins to cover with ice. The
HEATING mode automatically defrosts the device (remov-
ing the ice) to increase its efficiency. This process usually
takes up 2-10 minutes. The fans switch off for the duration
of the defrosting.
Once the defrosting has been completed, the air condi-
tioner automatically switches back into the HEATING mode.
PROTECTION
The protection mechanism can be triggered in the below
cases:
Heating
function
Outdoor temperature above 24 °C
Outdoor temperature below -7 °C
Room temperature above 27 °C
Cooling
function
Outdoor temperature above 43 °C
Room temperature below 21 °C
Drying
Room temperature below 18 °C
Notes: If the air conditioner is operated in COOLING
or DRYING mode with the door or window open for an
extended period of time with relative humidity above 80%,
condensation may drip from the exhaust vent.
Protection features
The protection will switch on in following cases:
– when restarting the air conditioner immediately after
stopping operation or changing the mode during opera-
tion - you must wait for 3 minutes.
