DESCRIPTION
1. Front panel
2. Outer lead-in
3. Cover
4. Side A (before connection)
5. Side B (after connection)
6. Body
7. Indoor unit
8. Outdoor unit
9. Freon line
10. Center hole
11. Plumb bob
12. Screw 4X25(5)
13. Indoor unit mounting plate
14. Polyethylene pipe
15. Large copper pipe
16. Thermal insulation of pipes
17. Small copper pipe
18. Drain pipe
19. Power cable
20. Control cable
21. Base
22. Pipes holder
23. Pipe clamp
24. Indoor unit control panel access lid
25. Vacuum pump
26. 3-way valve
27. Service port
28. Plug
29. 2-way valve
Installation and adjustment (assembly, connection,
start-up, etc.) of the product described in the docu-
mentation supplied therewith shall be performed by
a qualified technician or service company. Failure to
comply with this requirement may result in electric
shock, fire, explosion, damage to the product or inju-
ry, as well as loss of warranty for the unit installed.
Prior to any work on installation, commissioning, and
maintenance, require the presence of appropriate
permits (licenses, certificates, etc.) and a contract.
The person who installed and connected your prod-
uct is responsible for the correctness of the work
performed. Remember, qualified installation of the
product is essential for its further correct functioning
and warranty service. Make sure that the installer has
entered all the necessary information into the instal-
lation contract.
This manual is intended to familiarize you with the
general principles of installation of this model.
SAFETY MEASURES
Do not install, dismantle, or reinstall the unit yourself.
– The device is to be installed according to the
National Electrical Codes.
– Improper installation may result in water leakage, elec-
tric shock or fire. Contact an authorized dealer or tech-
nician to perform the installation. Please be aware that
faults resulting from improper installation are not cov-
ered by the warranty.
– The unit shall be installed in an easily accessible place.
Any additional costs for special equipment required to
service the unit will be paid by the customer.
– This unit is not intended for usage by children or dis-
abled people.
– Improper installation may cause injury due to fire, elec-
tric shock, device falling, or water leakage.
– Install the unit in a place that can bear its weight.
– If installed in an insufficiently strong place, the device
may fall and cause injury.
– Do not change the length of the power cord, do not use
extension cords or adapters.
RECOMMENDATIONS FOR SELF-INSTALLATION
OF THE AIR CONDITIONER
Preliminary preparation
Air-conditioner installation is difficult for a person firstly
encountering with such device. To ensure a correct and
a high-quality self-installation, you must be patient and
spend a certain amount of money on materials and some
special tool. You will need the following for your work:
copper pipes of different diameters (not supplied), heat-
insulating material for copper pipes, a 5х1.0 or 5х1.5
interunit PVS wire (control cable), a 3х1.0 or 3х1.5 electric
cable corresponding to the air conditioner capacity, an
earth connection plug, a ∅16 mm PVC drain hose, a set
of holders for outdoor unit installation (not supplied),
60x60 mm and 16x16 mm cable ducts; fasteners and
consumables: bolts, nuts, washers, clamps, an insulating
tape, fired pins, anchors, a reinforced tape, etc.; you will
also need the following tools: a large and a small punch-
ers, a set of drills of different diameters, a carpenter's level
or a plumb, a safety rope, a vacuum cleaner, a toolbox,
screwdrivers, a hammer, side cutters, knives, adjustable
wrenches, ratchets, etc.; pipe beading tools: a pipe cutter,
a chamfering rimmer, an expander; vacuuming and fill-
ing tools: a vacuum pump, a gauge manifold and a set of
hoses and connectors.
Sequence of work and recommendations
for installation
The installation of the air conditioner first of all starts with
the installation of the indoor unit mounting plate. It is fixed
strictly according to the level, or plumb line, in compliance
with certain heights relative to the ceiling and floor. To fix
the plate, use the indoor unit fixing kit, or the dowel-nails
with a size of 6×40mm. Use a suitable vacuum cleaner
when drilling holes to prevent contamination of the room.
After the mounting plate is mounted, mark the place for
drilling a hole for freon communications.
When marking the hole for freon communications, special
attention shall be paid to the level that will be located below
the level of the air conditioner itself, so that condensate
flows out of the indoor unit at a slight angle of 3-5° towards
the front wall. During drilling, you will need free access to
the place where a hole in the wall will come out from the
side of the front. Access is needed in order to be able
to catch small stones at the time when the drill passes
through the wall. To do this, if necessary, it may be neces-
sary to disassemble the window frame. For neat work in
the place of drilling the hole, you can attach a bag into
which all the dust will be poured during use of the ham-
mer drill. At this stage of work, you can also use a vacuum
cleaner, preventing dust and dirt from spreading in the
room. After completing the drilling of the hole, proceed to
the installation of the outdoor unit.
The outdoor unit is installed in most cases under a window
on the wall or on a solid foundation near the house, in a
convenient place for installation and further mandatory
maintenance of the air conditioner. The outdoor unit shall
