apply to door damage caused by its re-hinging. Any repairs caused by such

circumstances will be performed at the cost of the owner.

4.1. VENTILATION

The compressor and condenser of the refrigerator heat up during operation,

therefore sufficient ventilation should be provided for cooling.

– The refrigerator should be installed in a well-ventilated room with normal

humidity. Never install the refrigerator in rooms with high humidity, e.g. in

bathrooms or basements.

– Ensure that gaps of at least 3 to 5 cm on the sides and 10 cm above the top

are provided during installation for free air circulation. Do not obstruct air

movement at the back side of the appliance.

– Do not place the appliance near heat sources.

– Do not install the refrigerator so that it is exposed to direct sunlight or near

heat sources (kitchen ovens, cookers, fireplaces, etc.).

4.2. LEVELING

It is important that the refrigerator is installed on a level surface for efficient

operation. After placing the refrigerator at its permanent location adjust its

position by turning the adjustable front feet. The refrigerator should not be

slanted backwards by more than 5°.

4.3. CONNECTING TO POWER SUPPLY

The refrigerator complies with Class 1 requirements for protection against

electric shock and is connected to the power supply grid by a two-pole plug with

an earthing contact. Before connecting to power supply ensure that:

– the grid voltage corresponds to that indicated on the data plate located on the

back side of the refrigerator;

– the earthing contact of the electric socket is connected to an earthing

conductor of the mains cable (the earthing conductor should have a minimum

rating of 10 A);

– the power socket and plug should be of the same type; if the plug does not fit

the socket the latter should be replaced with one compatible with the plug

(this work should be performed by a skilled electrician).

The refrigerator should be placed so that you would always have access to

the power socket. A refrigerator improperly connected to power supply, i.e.

incompliant with the requirements for powerful home appliances set forth in

this manual, is potentially dangerous. The manufacturer shall not be made liable

for damage to human health and property if such damage is caused by non-

observance of the installation requirements specified herein.

5. OPERATING THE REFRIGERATOR

5.1. BEFORE TURNING ON

After installing the refrigerator please wait for approx. three hours before

connecting it to power supply. This way you will allow the refrigerant to be

properly distributed: this is necessary for proper operation of the refrigerator.

You will be able to place food in the refrigerator within a few hours after

connecting it to power supply. Remove the transportation inserts between the

compressor and the back wall of the niche, as well as all other inserts and

adhesive tape preventing the movable parts of the appliance from displacement

during transportation.

If the appliance is covered in a protective polymer film, carefully remove it, taking

precautions not to damage the paint or polymer coatings in the components.

5.2. INITIAL OPERATION

DISPLAY

– When the refrigerator power is turned on the display will light up for 3

seconds. Then an audio signal will be emitted and the display will switch to

normal operation readings.

– When the refrigerator is used for the first time the default cooling chamber

temperature will be 4 °С and that of the freezing chamber will be -18 °С.

– In case of a malfunction an error code will appear on the display (see Error

Code Table). During normal operation the display shows the temperature

settings for the cooling or freezing chamber.

– In normal conditions, if no controls are operated or the door is not opened for

30 seconds, the display will be locked and the lock indicator

will turn off.

LOCKING/UNLOCKING

– In the unlocked state, press and hold the lock button (11) for 3 seconds, the

indicator will turn off and an audio signal will be emitted: this means that the

control panel is locked and the appliance cannot be operated.

– In the locked state, pres and hold the lock button (11) for 3 seconds, the

indicator will turn on and an audio signal will be emitted: this means that the

control panel is unlocked and appliance controls are now available.

COOLING CHAMBER TEMPERATURE SETTING

Press the TEMP. SELECT button (8), to select the temperature setting for the

cooling chamber, then press

or to adjust the cooling chamber temperature

setting. The temperature setting for the cooling chamber can range from 2 °C

to 8 °C.

FREEZING CHAMBER TEMPERATURE SETTING

Press the TEMP. SELECT button (8), to select the temperature setting for

the freezing chamber, then press

or to adjust the freezing chamber

temperature setting. The temperature setting for the freezing chamber can

range from -24 °C to -16 °C.

TEMPERATURE

CONTROLLED CHAMBER TEMPERATURE SETTING

Press VARIO TEMP. button (10) to adjust the temperature setting in the chamber

(4). Press the button multiple times to select the desired temperature control

mode: fruit/vegetables, beverages, meat.

SUPERCOOLING AND SUPERFREEZING MODE SETTINS

– Setting the supercooling mode: after the temperature in the cooling chamber

has been set 2 °C, press the temperature decrease button

to switch to the

supercooling mode. In the supercooling mode the temperature in the cooling

chamber is automatically set to 2 °C.

– Cancelling the supercooling mode: press the temperature increase button

to exit the supercooling mode, or wait for automatic deactivation of

the supercooling mode after 6 hours of operation. After supercooling mode

deactivation the temperature in the cooling chamber will automatically return

to the value set before supercooling mode activation.

– Setting the superfreezing mode: after the temperature in the freezing

chamber has been set -24 °C, press the temperature decrease button

switch to the superfreezing mode. In the superfreezing mode the temperature

in the freezing chamber is automatically set to -24 °C.

– Cancelling the superfreezing mode: press the temperature increase button

to exit the superfreezing mode, or wait for automatic deactivation of the

superfreezing mode after 32 hours of operation. After superfreezing mode
