Селективный металлодетектор «Сигнум MFT» 7272М. Руководство по эксплуатации.
6
ООО «фирма «АКА», +7(495)621-0481, http://aka.2000.ru aka_md@mail.ru
GETTING STARTED
Assemble the metal detector. To do this:
- install the appliance in a metal bar;
- tighten the Collet Chuck;
- install the inner (plastic rod) sensor;
- install the rod with the sensor in a metal bar to desired length, using the tabs and
holes in the rod
- tightly and evenly wrap the sensor cable around the rod. Freely hanging cables can
Cause falsing;
- connect the sensor connector to the electronic unit.
WARNING!
Do not over tighten the attachments and fittings for the telescopic
shaft. This applies in particular to the
plastic bolt for the search coil
and shaft collets.
Thanks to a specially designed three-knee construction
shafts do not need to be disassembled for transportation,
simply push the knee shafts into each other all the way
and the device is ready to be carried compactly (fig. 1)
POWER SUPPLY
The device is powered using 6 AA
batteries or 6 rechargeable NIMH. Rechargeable
batteries and charger are not included and must
be purchased separately. We recommend that
you use NiMH batteries from SANYO, ANSMANN
2500 capacity-VARTA or 2850 Ma/h. The use of
standard alkaline batteries is possible but not cost
effective as the rechargeable batteries pay off
after 4-5 recharges.
fig 1
When using batteries, with a capacity of 2500 Ma/h, continuous operation is
approximately 16 hours in the main mode and 6-7 hours in Turbo mode.
Several recommendations on the use of nickel-metal hydride batteries:
-Avoid fully discharging the batteries with each cycle use as this shortens their
lifespan. Slight "memory effect" is eliminated by one complete discharge approximately
once a month.
-After extended periods, of storing the device, it is usually good practice to
fully discharge and charge the batteries a total of 4-5 times.
-Remember that due to the self-discharge nature of the batter capacity falls (by
About 5% per day
, so it is advisable to charge batteries before each use.
-DO NOT use rechargeable batteries that have different capacities in the same set.
WARNING!
When connecting the battery magazine to the device connector insure
the battery is properly connected (polarity is indicated on the battery cartridge) and
insure the voltage source is correct.
In the case of incorrect polarity or improper voltage the
device can be damaged
.
