If the switch (5) is OFF, that means that the line laser is o, the compensator

is also locked.

3. Press button (1) to switch the vertical beam on. Press button (1)once again

to switch the horizontal beam on. Press button (1) to switch the horizontal

and vertical beams on. Switch on only necessary laser lines in order to save

battery life.

4. Press button (2). The mode “outside” is activated. Press button (2) once

again. The tool begins to operate in “inside” mode. Use the detector of laser

beam for this mode. See the operating manual for the operation with detector.

TO CHECK THE ACCURACY

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Place line laser on the tripod 5m away from the wall so the horizontal laser

line will be directed to the wall.

Switch on the power. The line laser starts to self-level. Mark point A on the

wall to show the contact of laser beam with the wall. Turn the line laser by

90° and mark points В, С, D on the wall. Measure distance “h” between the

highest and lowest points (these are A and D points in the picture).

If “h”is ≤ 6 mm, the measurement accuracy is good. If “h” exceeds 6 mm,

apply service center.

TO CHECK PLUMB

Choose a wall and set laser 5m away from the wall. Mark point A on the

wall, please note the distance from point A to ground should be 3m. Hang

a plumb line from A point to ground and nd a plumb point B on ground.

turn on the laser and make the vertical laser line meet the point B, along

the vertical laser line on the wall and measure the distance 3m from point

B to another point C. Point C must be on the vertical laser line, it means the

height of C point is 3m.

Measure the distance from point A to point C, if the distance is over 2 mm,

please, contact with seller to calibrate the laser.
