4 English

CHANGE OF BATTERIES

Open battery compartment. Insert batteries. Take care to correct polarity.

Close battery compartment. ATTENTION: If you are not going to use instru-

ment for a long time, take out batteries.

OPERATION

Cube 360 is a reliable and convenient line laser. It will be irreplaceable

tool for many years. Before use, remove battery compartment cover. In-

sert three batteries into battery compartment with proper polarity, then

put the cover back. Set the compensator locking grip (5) into ON position,

two laser beams will be on. If the switch is ON,that means the power is on

and the compensator is working. Visual alarm (blinking line) and audible

signal indicate that the device was not installed within the compensation

range ± 4 º. To properly work align the unit in a horizontal plane. If the

switch (5) is in intermediate position, that means the power is opened,the

compensation is still locked, but it will not warn if you issue the slope. It’s

the hand-mode. If the switch (5) is OFF, that means that the line laser is

o, the compensator is also locked. Press button (1) only once- horizontal

beam will turn on. Press the button (1) one more time - vertical laser beam

will turn on. Again press the button (1) - horizontal and vertical beams will

turn on. Press button (2) once. Otdoor mode is activated. Press button (2)

one more time. The line laser begins to work in indoor mode.

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Place line laser on the tripod 5m away from the wall so the horizontal laser

line will be directed to the wall. Switch on the power. The line laser starts

to self-level. Mark point A on the wall to show the contact of laser beam

with the wall. Turn the line laser by 90° and mark points В, С, D on the wall.

Measure distance “h” between the highest and lowest points (these are A

and D points in the picture). If “h”is ≤ 6 mm, the line laser accuracy is good.

If “h” exceeds 6 mm, apply service center.
