4 English

CHANGE OF BATTERIES

Open battery compartment. Insert batteries. Take care to correct polarity.

Close battery compartment. ATTENTION: If you are not going to use instru-

ment for a long time, take out batteries.

OPERATION

Place the line laser on the working surface or mount it on the tripod/pillar

or wall mount (comes with the instrument). Switch on the line laser: turn

the compensator switch (3) to the position “ON”. When enabled, the ver-

tical and horizontal plane projected constantly. Visual alarm (blinking line)

indicates that the device was not installed within the compensation range

± 3 º. To properly work align the unit in a horizontal plane.

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Set up the line laser between two walls, the distance is 5m.Turn on the Line

Laser and mark the point of cross laser line on the wall. Set up the instru-

ment 0,5-0,7m away from the wall and make, as described above, the same

masrks. If the dierence {a1-b2} and {b1-b2} is less then the value of “ac-

curacy” (see spesications), there is no need in calibration. Example: when

you check the accuracy of Cross Line Laser the dierence is {a1-a2}=5 mm

and {b1-b2}=7 mm. The instrument’s error: {b1-b2}-{a1-a2}=7-5=2 mm.

Now you can compare this error with standard error.

If the accuracy of Line Laser isn’t corresponding with claimed accuracy,

contact the authorized service center.

TO CHECK THE ACCURACY OF HORIZONTAL BEAM

Choose a wall and set laser 5M away from the wall. Turn on the laser and

cross laser line is marked A on the wall. Find another point M on the hori-

zontal line, the distance is around 2.5m. Swivel the laser, and another cross
