25 Rope
26 Elastic rope-intake limiter
27 Load hook
28 Hex key (4 mm)
29 Set screw for load-capacity adjustment
30 Rope clamp for securing the free rope end
31 Rope grip for adjustment of rope length
32 Rope fastener of rope-intake limiter
The accessories illustrated or described are not included as stan-
dard delivery.
Technical Data
Assembly
The device onto which the suspension quick-link 2 and
the securing eye 4 of the balancer or spring pull are to
be attached must be dimensioned with with a safety
factor of 5. For safe operation with the balancer or spring
pull, calculate the weight of the balancer or spring pull (see
“Technical Data”) plus the maximal load capacity (weight
of the attached tool) and multiply the sum by 5.
Immediately replace balancers and spring pulls that
have fallen down or crashed! Have damaged balancers
and spring pulls repaired through an authorized customer
service agent for Bosch power tools.
Mounting a Balancer
Type 0 607 950 938 | ... 939
Mount the balancer via suspension quick-link 2 to a stationary
mounting location with sufficient stability.
Tighten lock nut 3 on suspension quick-link 2 so that the bal-
ancer can not slip or jump out of the suspension quick-link.
Fasten securing eye 4 independent from suspension quick-
link 2.
Pay attention that the movability of the balancer is not im-
paired by the safety chain 1. A back and forth motion in the di-
rection of the balancer must be possible.
The possible falling distance in case of falling down must not
exceed 1 m.
Balancer
Article number 0 607 950 ... ... 938 ... 939
Load capacity range
kg
lbs
0.4–1.2
1.9–2.6
1.2–2.2
2.6–4.8
Max. compressed-air supply bar
psi
10
145
10
145
Connecting thread
G1/4"
Inside hose diameter
mm
in
5
0.2
5
0.2
Max. hose-extension length
mm
in
800
31.5
800
31.5
Weight according to EPTA-Procedure 01:2014
kg
lbs
1.3
2.9
1.4
3.1
Spring pull
Article number 0 607 950 ... ... 950 ... 951 ... 952 ... 953 ... 954
Load capacity range
kg
lbs
0.5–1.2
1.1–2.6
1.0–2.0
2.2–4.4
0.3–1.5
0.7–3.3
1.2–2.5
2.6–5.5
2.0–5.0
4.4–11.0
Max. rope extension length
mm
in
2000
78.7
2000
78.7
1600
62.9
1600
62.9
3000
118.1
Weight according to
EPTA-Procedure 01:2014
kg
lbs
0.41
1.3
0.41
1.3
0.46
1.1
0.49
1.3
3.5
7.3
Spring pull
Article number 0 607 950 ... ... 955 ... 956 ... 957 ... 958
Load capacity range
kg
lbs
4.0–8.0
8.8–17.6
7.0–10.0
15.4–22.0
0.4–1.2
1.9–2.6
1.2–2.6
2.6–5.7
Max. rope extension length
mm
in
3000
118.1
3000
118.1
1500
59
1500
59
Weight according to EPTA-Procedure 01:2014 kg
lbs
3.7
8.2
3.7
8.2
1.3
2.9
1.4
2.9
