Not for

Reproduction

We recommend you contact an Authorized Service Dealer for

all maintenance, adjustments, and servicing of the unit. The

owner can do some routine maintenance tasks. Refer to the

maintenance schedule and procedures that follow.

CAUTION

All the components used to build this product must remain

in place for correct operation. Replacement parts must be

of the same design and installed in the same position as the

original parts. Other parts may not perform as well, damage

the unit, and result in injury.

WARNING

This snowthrower must be correctly maintained to ensure

safe operation and performance. Failure to obey the safety

instructions in this manual could result in death or serious

injury.

• Before maintenance or repairs on the snowthrower,

STOP the engine and remove the ignition key or the

push/pull key.

Maintenance Schedule

First 5 Hours

Change the oil.

Before Each Use

• Check the engine oil level.

• Check the auger stop time.

After Each Use

Remove accumulated snow and slush to prevent freezing of the controls,

wheels, discharge chute, and auger.

Every 25 Hours or Annually

• Check the scraper bar for wear.

• Change the engine oil.

• Check the snowthrower for loose hardware.

• Check the auger control cable adjustment.

• Check the muffler and muffler guard.

• Replace the spark plug (dealer service).

• Check the valve clearance* (dealer service).

* Not required unless problems are noted with engine performance.

Emissions Control

Maintenance, replacement, or repair of the emissions control

devices and systems can be serviced by a non-road engine

repair establishment or individual. However, to obtain “no

charge” emissions control service, the work must be serviced

by a factory authorized dealer.

Change the Engine Oil

Use Briggs & Stratton Synthetic 5W-30 Warranty Certified oil

for best performance. Other high-quality detergent oils are

acceptable if classified for service SG, SH, SJ or higher. Do

not use additives.

1. STOP the engine, and turn the ignition key to the OFF

position. Remove the ignition key, or pull out the Push/

Pull key (if equipped).

WARNING

Fuel and its vapors are extremely flammable, which could

cause burns or fire resulting in death or serious injury.

• During maintenance, tilt the unit, and drain the fuel

tank. Fuel leakage can result in a fire or explosion.

2. Remove the oil drain plug (D, Figure11). Tilt the

snowthrower a small distance forward and drain the oil

into an approved container.

3. Install and tighten the oil drain plug.

4. Put the unit on a level surface.

5. Clean the oil fill area.

6. Remove the dipstick (A, Figure12).
