7. Slowly add oil into the oil fill. Do not

overfill.SeeSpecificationsfor the oil capacity.

8. Wait one minute. Check the oil level again.

9. When the oil level touches the top of the full indicator (B),

install and tighten the dipstick.

Adjust the Auger Control Cable

DANGER

The discharge chute contains a rotating auger that throws

snow. Fingers or feet can quickly become caught in

the auger and result in traumatic amputation or severe

laceration.

• Over-tightening the auger cable may cause the auger to

rotate even if the auger control lever is not engaged.

The auger must rotate only when the auger control is

engaged. When the auger control is released,the auger

must stop within 5 seconds. If the auger does not rotate or

stop, adjust the control cable or contact an authorized service

dealer.

1. STOP the engine. Remove the ignition key or the Push/

Pull key.

2. Lift the cable cover (A, Figure13) to expose the

adjustment loops (B)and the cable end fitting (C).

3. Move the cable end fitting to the correct adjustment loop:

• If the auger rotates when the auger control

isdisengaged, attach the end-fitting to the next

lowest loop. This will decrease the belt tension.

• If the auger does not rotate when the auger control

is engaged,attach the end-fitting to the next highest

loop. This will shorten the control cable and increase

belt tension.

Note:Some slack must remain in the cable when the auger

control is disengaged.

4. Lower the cable cover into position.

5. Use the test below and check the operation of the auger

control. If the unit does not operate as described, DO

NOT use it. Contact an authorized service dealer.

Test the Auger Control

• Start the engine.

• Pull the auger control lever against the handle.Make

sure that the auger rotates.

• Release the auger control lever.The auger must

stop within 5 seconds.

Auger and Scraper Bar

1. STOP the engine and remove the ignition key or the

Push/Pull key.

2. Inspect the wear limit on the rubber auger (A, Figure14).

If the rubber auger is worn, replace the two rubber

flights.Contact an Authorized Service Dealer.

3. Inspect the gap between the scraper bar support and the

ground (B).If the scraper bar support touches the ground,

replace the scraper bar. Contact an Authorized Service

Dealer.
