Replacing the Impeller Shear Bolts

DANGER

The snowthrower contains a rotating auger and impeller that

throws snow. Fingers or feet can quickly become caught in

the auger or impeller resulting in traumatic amputation or

severe laceration.

• STOP the engine, wait for all moving parts to stop, and

remove the engine key before maintenance or repairs.

1. STOP the engine. Remove the engine key.

2. Remove the existing shear bolts (A, Figure26) and

locknuts (C)from the impeller shaft (B).

3. Align the bolt holes. Install the new shear bolts through

the auger shaft. Tighten with the locknuts.

Checking Tire Pressure

WARNING

Explosion hazard

Over-inflation of tires can cause them to explode, which

could result in serious injury.

Do not inflate the tires above the maximum pressure.

Tire pressure should be checked periodically. Recommended

tire pressure varies by tire manufacturer. A good rule of

thumb is to inflate the tire up to, but not exceeding, the “Max

Inflation” stamped on the side-wall of the tire.

Storage

Storage - Fuel System

Fuel can become stale when kept in a storage container

for more than 30 days. Each time you fill the container

with fuel, addfuel stabilizerto the fuel as specified by the

manufacturer’s instructions. This keeps fuel fresh and

decreases fuel-related problems or contamination in the fuel

system.

It is not necessary to drain fuel from the engine whenfuel

stabilizeris added as instructed. Before storage, turn the

engine ON for 2 minutes to move the fuel and stabilizer

through the fuel system.

Off-Season Storage

At the end of the season, or when the unit is in storage for

more than 30 days, complete the steps that follow.

WARNING

Gasoline is highly flammable and its vapors are explosive.

Fumes can move to a distant ignition source and an

explosion and/or fire can result.

• If fuel is in the tank, do not keep the unit indoors or

in poorly ventilated areas where fumes could reach

sparks, open flames, pilot lights, heat, and other ignition

sources.

Snowthrower

• Clean the unit. Make sure that all nuts, bolts, and screws

are tightened.

• Examine visible moving parts for damage, breakage,

and wear. Replace if necessary.

• Lubricate the control lever linkages, chute and

deflector, auger assembly, and drive wheel axles.

SeeMaintenance and Adjustments.

• For rusted or chipped paint surfaces, sand lightly and

apply touch-up paint.

• For unpainted or bare metal surfaces, apply a rust

preventative product.

• Keep the unit indoors and cover it. If kept outdoors,

cover it with a heavy tarpaulin.

Returning the unit to Service

• Contact an Authorized Service Dealer for annual

maintenance tasks. SeeMaintenance Schedule.

• Inspect engine oil level and add oil, if necessary.

• Fill the fuel tank with clean fuel.

• Check tire pressures.

• Make sure that all guards, shields, and covers are

attached.

• Make sure that all fasteners are tightened.

• Inspect the auger and impeller control, and the traction

drive control.
