STATUS CP 115 07410601 [8/36] Operation

• Prior to performing a cut, check wood for presence of extraneous objects (wedges,

nails, pebbles, etc.).

• In case the chain and/or guide bar jams: stop the machine, unplug the cable from

mains, use non-metal tool to release the chain without applying extensive force.

• It is recommended that the rst time user should have practical instruction in the use

of the chain saw and the protective equipment from an experienced operator and that

the initial practice should be cutting logs on a saw horse or cradle.

• Power tools must not be used outdoors in rainy weather, or in moist environment (after

rain) or in close vicinity with easily ammable liquids and gases. The working place

should be well lit.

TOOL PARTS OVERVIEW

OPERATION

TOOL PARTS OVERVIEW

OPERATION

1. Grip surface

2. Guard

3. Chain scabbard

4. Limit stop

5. Lockout lever

6. Saw chain

7. Guide bar

8. Chain sprocket (not shown)

9. Nut

10. Chain sprocket cover

11. Battery state indicator

12. Button

13. Trigger switch

14. Control handle

15. Battery compartment

16. Battery

17. Charger

CHARGING BATTERY PACK (Fig. 3)

FITTING AND REMOVING THEBATTERY PACK

To remove the battery: Press release button (16) in the indicated direction (A) and pull the

battery out of the machine body. (B)

To insert the battery: Place the battery into the base of the machine and slide it until it locks

with an audible click. (C)

Ligts Status

Green on Plugged in / Fully charged

Red on Charging in progress
