BATTERY STATE INDICATION

The battery state during operation can be checked on the LED display (11) by pressing the

button (12).

Depending on the number of illuminated LEDs the batterystate is as follows:

4 LEDs are burning - the level of charge is 100%.

2-3 LEDs are burning - the level of charge is 40-70%.

1 LED is on - charge level is 25-30%.

SWITCHING ON - SWITCHING OFF

• Turn machine in by pressing button 12.

• Hold the saw rmly with one hand on the grip area of the control handle (14) – wrap

your thumb around the control handle.

• Hold and control the tool with your other hand on the grip surface (1).

• Depress the lockout lever (5) with your thumb and hold it there.

• Pull the trigger (13) with your index nger and hold it there.

• The motor accelerates and the chain rotates.

WARNING: Always switch o and unplug the power tool prior to any inspection or

maintenance. To ensure product long life and safe operation, perform the below described

maintenance procedures regularly.

WARNING: Always wear protective gloves when handling the guide bar and chain.

Regularly check for obvious defects such as loose, stretched or damaged chain and guide

bar, loose xings and worn or damaged components. Check that covers and safety devices

are undamaged and correctly tted. Carry out necessary maintenance before using the

chain saw. If the chain saw is faulty, repair should be carried out in authorized SPARKY

service centre.

NOTE: Before returning the chain saw to an authorized service centre ensure that the oil

tank has been emptied completely.

REPLACING THE GUIDE BAR AND CHAIN

Fit the chain and guide bar as described above. The guide bar groove wears with time.

The bar side contacting with the machine should be reversed periodically to ensure

uniform wear. Check the drive sprocket (19). If it has worn out or damaged due to strain,

have it replaced in authorized service centre. If the chain has worn out or damaged,

have it replaced in authorized service centre.

BAR TIP SPROCKET LUBRICATION

NOTE: It is not necessary to remove the chain in order to lubricate the bar tip sprocket.

Lubrication can be done on the job.

MAINTENANCE
