STATUS SH 125 E UniOne 03052901 [11/60] Operation

OPERATION

• Use only grinding discs whose permissible speed rating is at least as high as that on the

type plate on the power tool.

• RISK OF INJURY! Press the spindle locking button only when the mounting spindle is at

a complete standstill.

• Press the spindle locking button to lock the motor.

• Undo the clamping nut using the two-hole mounting spanner

• Place the rough grinding or cutting disc with the label side towards the appliance on

the mounting ange .

• Then replace the clamping nut with the raised side facing up on the mounting spindle.

With thin grinding discs

• The collar of the clamping nut faces upwards so that a thin grinding disc can be tted

safely.

• Press the spindle locking button to lock the motor.

• Tighten the clamping nut using the two-hole mounting spanner .

With thick grinding discs

• The collar of the clamping nut faces downwards so that the grinding disk can be tted

securely onto the mounting spindle .

• Lock the mounting spindle .

• Tighten the clamping nut in a clockwise direction using the two-hole mounting

spanner .

• For safety’s sake, run the appliance at maximum speed for 60 seconds after every disc

change. Be aware of unusual noises and sparks.

• Check whether all the fastening elements are correctly tted.

• Make sure that the arrow showing the direction of rotation (if any) on the cutting or

rough grinding discs (including diamond cutting discs) and the direction of rotation of

the appliance (arrow showing the direction of rotation on the head) match.

Working procedures

NOTE: Grinding tools should only be used for the recommended applications.

Otherwise, theymcan break, be damaged or cause injuries.

Rough grinding: Never use cutting discs for rough grinding!

■ While applying moderate pressure, move the angle grinder back and

forth over the workpiece.

■ For soft material, move the rough grinding disc at a shallow angle over

the workpiece; for hard material at a slightly steeper angle.

Abrasive cutting: Never use roughing discs for cutting!

■ Use only tested bre-reinforced cutting or grinding discs that are

approved for a circumferential speed of not less than 80 m/s.
