16 ENGLISH
OPERATION
Holdthetoolrmlywithonehandontheknobandthe
other hand on the switch handle when operating the tool.
Planing operation
First,restthetoolfrontbaseatupontheworkpiecesurfacewithout
thebladesmakinganycontact.Switchonandwaituntiltheblades
attainfullspeed.Thenmovethetoolgentlyforward.Applypressure
onthefrontoftoolatthestartofplaning,andatthebackatthe
endofplaning.Planingwillbeeasierifyouinclinetheworkpiecein
stationaryfashion,sothatyoucanplanesomewhatdownhill.
Thespeedanddepthofcutdeterminethekindofnish.
The tool keeps cutting at a speed that will not result in
jammingbychips.Forroughcutting,thedepthofcutcan
beincreased,whileforagoodnishyoushouldreduce
thedepthofcutandadvancethetoolmoreslowly.
►Fig.24: 1. Start 2.End
Shiplapping (Rabbeting)
►Fig.25
Tomakeasteppedcutasshowninthegure,usethe
edgefence(guiderule).
Install the edge fence on the tool. Secure it with the washer
andthumbscrew(A).Loosenthethumbscrew(B)andadjust
the edge fence until it comes in contact with the side of the
workpiece.Thentightenthethumbscrew(B)securely.
►Fig.26: 1.Screw(A)2.Screw(B)3.Edgefence
Drawacuttinglineontheworkpiece.Aligntheblade
edge with the cutting line.
Adjusttheshiplappingdepthusingadepthguide.
Whenplaning,movethetoolwiththeedgefenceushwiththe
sideoftheworkpiece.Otherwise,unevenplaningmayresult.
►Fig.27: 1. Blade edge 2. Cutting line 3. Depth guide
NOTICE:
Thebladeedgeshouldbemadetoprotrude
outsideslightly(0.2mm-0.4mm)forshiplapping.
►Fig.28
Youcanextendthelengthofthefencebyattachinganextrapieceof
wood. Convenient holes are provided in the fence for this purpose.
►Fig.29
Chamfering
►Fig.30
Tomakeachamferingcutasshowninthegure,align
oneofthree"V"groovesinthefrontbasewiththeedge
of the workpiece and plane it.
►Fig.31: 1.Vgroove(mediumamountofchamfering)
2.Vgroove(smallamountofchamfering)
3.Vgroove(greatamountofchamfering)
Useofchamferingrule(optionalaccessory)assures
moretoolstabilitywhenchamfering.
To install the chamfering rule, remove two screws on
bothsidesofthefrontofthetool.
Theninstallthechamferingruleonthefrontbaseofthe
toolandsecureitthescrewsasshowninthegure.
►Fig.32: 1. Chamfering rule 2. Screw
When doing a great amount of chamfering, place an edge
of chamfering rule so that it contacts workpiece and make
manypassesofplaningasshowninthegure.
►Fig.33: 1.Edgeofchamferingrule
WIRELESS ACTIVATION
FUNCTION
What you can do with the wireless
activation function
Thewirelessactivationfunctionenablescleanandcom-
fortableoperation.Byconnectingasupportedvacuum
cleanertothetool,youcanrunthevacuumcleaner
automaticallyalongwiththeswitchoperationofthetool.
►Fig.34
To use the wireless activation function, prepare follow-
ingitems:
• Awirelessunit(optionalaccessory)
• Avacuumcleanerwhichsupportsthewireless
activation function
The overview of the wireless activation function
setting is as follows. Refer to each section for detail
procedures.
1. Installing the wireless unit
2. Tool registration for the vacuum cleaner
3. Starting the wireless activation function
Installing the wireless unit
Optional accessory
CAUTION: Place the tool on a at and stable
surface when installing the wireless unit.
NOTICE: Clean the dust and dirt on the tool
before installing the wireless unit. Dust or dirt
maycausemalfunctionifitcomesintotheslotofthe
wireless unit.
NOTICE: To prevent the malfunction caused by
static, touch a static discharging material, such
as a metal part of the tool, before picking up the
wireless unit.
NOTICE: When installing the wireless unit,
always be sure that the wireless unit is inserted
in the correct direction and the lid is completely
closed.
1. Openthelidonthetoolasshowninthegure.
►Fig.35: 1. Lid
2. Insert the wireless unit to the slot and then close
the lid.
Wheninsertingthewirelessunit,aligntheprojections
with the recessed portions on the slot.
►Fig.36: 1. Wireless unit 2.Projection3. Lid
4. Recessed portion
Whenremovingthewirelessunit,openthelidslowly.
Thehooksonthebackofthelidwillliftthewirelessunit
asyoupullupthelid.
►Fig.37: 1. Wireless unit 2. Hook 3. Lid
Afterremovingthewirelessunit,keepitinthesupplied
case or a static-free container.
