DKVM-IP16LCD
3
ENGLISH
Press
...
...then press
...then press
...then press
Home + Home
Caps Lock
Enter Caps Lock Hot Key mode
Scroll Lock
Num Lock
...then press
/
2
...then press
...then press
/
...
or
or
Enter Hot Key mode by default
Switch to PC1 / PC2 / ...
Switch to next PC
Switch to previous PC
Enter Scroll Lock Hot Key mode
Enter Num Lock Hot Key mode
...then press
Start autoscan mode, which will switch to the next PC
automatically after scan interval expires (5 seconds
...then press
Toggle the audible beep conrmations on and off
by default). Press any key to stop autoscan mode
Note: Hot Keys can be achieved under OSD mode. Press Home + Home + Enter to enter
OSD menu.
Username: admin
The DKVM-IP16LCD default settings:
Configuring the DKVM-IP16LCD
Note: You can remotely control the DKVM-IP16LCD using the 5.0 (V1.5) JRE (Java Runtime Environment)
program platform. You can download it from the following website: http://www.java.com/.
DHCP: Disabled
Password: 12345
IP address: 192.168.1.101
Subnet mask: 255.255.255.0
You can use a Web browser to configure the DKVM-IP16LCD. The computer, which will be used for
configuring the KVM switch, should have an IP address in the same range as the DKVM-IP16LCD. In
order to enter the Web-based GUI, please open a Web browser and enter the IP address of the
KVM switch in the address bar. Then press Enter. When the dialog box appears, enter the
username and the password. Press Login.
The DKVM-IP16LCD features the buttons located above built-in keyboard to switch quickly and
easily between your computers.
Switching with the DKVM-IP16LCD
Note: Don't switch PC without finishing PC boot-up.
Caps Lock / Scroll Lock / Num Lock
Hot Keys
You can also use keyboard
Home /
to switch between your computers. Press the
key twice within 2 seconds to enter Hot Key switching mode.
Hot Keys
Hot Key mode. Alternatively, you can use the Caps Lock, Scroll Lock or Num Lock keys.
A beep confirms that the Hot Key mode is activated. By default, the Home key is used to enter the
Note: If you are using OSD, you can click directly when you are on the main menu. Because
under the OSD menu, you can press ↓ and ↑ keys to move the corresponding port. Then press
Enter key, the DKVM-IP16LCD will switch to this input.
Note: You can use Home + Home + F11 + Enter to reset the KVM switch.
Note: Press and hold the Reset button on the console panel for 10 seconds to restore the default settings.
Wait until resetting the settings is completed (5 seconds), then disconnect and connect the power adapter
to the electrical network again. After the device is booted (1 minute), it will be accessible via its default
IP address.
