4. Exploded View

Water Block Assembly

Fixing Bolt for Clip Support

Clip Support for Socket 775

Clip Support for Socket 478

Backplate for Socket 775

Clip for Intel

Retention Guide

Clip for AMD

ZM-WB4 Plus/ZM-WB5

Retention Guide for AMD

IInntteell ((SSoocckkeett 777755)) IInntteell ((SSoocckkeett 447788))

((OOnnllyy iinn ZZMM--WWBB44 PPlluuss))

※※CClliipp CCoommbbiinnaattiioonnss ffoorr IInntteell

Overlap the left and right Clips as shown

in the picture above, and assemble them

with the use of Bolts.

AAMMDD ((SSoocckkeett AAMM22//775544//993399//994400))
