7
.COM
6. Fan Mate 2 Installation and Usage
1) Fan Mate 2 Installation
2) Fan Mate 2 Usage
①
Connect the motherboard and
Fan Cable to the Fan Mate
2 as shown in the diagram
below.
Rotating the Fan Speed Control
Knob for RPM control.
②
Fan Mate 2 can be installed to the
side of the case using Double-Sided
Tape.
M/B
Fan Connector
(Cooler)
Fan Speed Control Knob
Double-Sided Tape
In the case that you get a BIOS error beep:
①
Rotate the Fan Speed Control Know to the maximum setting.
②
Disable CPU Fan Detected in BIOS setting or set the system monitoring
program’s CPU Fan RPM to the lowest setting.
※
Certain motherboards will not boot if the CPU fan’s RPM is not detected. In this
caseinquiretothemotherboard’smanufacturerforadditionaldetails.
BIOS booting error
