English
48 49
Warning
• The symbol on the right shows that it is advisable to carefully
follow the highlighted instructions. Failure to respect these
instructions may cause unintentional harm or damage
to the components.
• Before installing the components, please carefully read all of the instructions contained
in this manual.
• In order to simplify the installation, prepare a detailed plan of your installation configuration and
connect the cables safely and neatly.
• Always wear protective eyewear when using tools.
• In order to avoid possible damage, store the product in its package during installation
construction.
• All of the structures built to house the different components must be firmly and reliably attached
to the vehicle chassis using brackets, screws, nuts and bolts, in order to ensure a solid and safe
installation.
• If the component comes loose from the vehicle chassis while driving, this may cause serious
damage to the vehicle and injury to passengers in the car. Attach the components properly, with
the utmost care, especially in the case of installation inside the vehicles interior.
• Do not carry out any installation inside the engine compartment.
• Before you start the installation, turn off the head unit and all the electronic devices of the audio
system in order to avoid any damage and disconnect the negative battery terminal.
• Make sure that the location you chose for the components does not hinder the correct
functioning of any mechanical or electric device in the vehicle.
• Do not put cables or install the components close to electronic or mechanical devices.
• Be very careful when you drill or cut into the vehicle chassis, and make sure that no cables
or structural elements essential to the car are underneath or in the selected area.
• The connecting cable must have an insulation which is mechanically resistant and
self-extinguishing in the case of fire. The cable section must have the size indicated herein.
When you route the cable, do not press the cable against sharp edges or near a moving
mechanical device. Make sure that it is firmly attached and protected for its entire length.
• Protect the conductor with a rubber ring (grommet) if it passes through a hole in the vehicle
chassis or with proper protection materials if it runs close to heat-generating parts.
• Do not pass the wires outside the vehicle; this is not reliable or safe.
• When you install the components and their connecting cables, make sure that they do not touch,
even occasionally, any part of the cars chassis. In this case, the amplifier protection triggers.
• In order to avoid any problems, use top quality cables, connectors and accessories choosing
them in the CONNECTION Audison catalogue.
• Once your installation has been completed, check the system wiring again for proper connection
before turning the system on.
Warranty Restrictions
Please read the warranty terms carefully and keep both the manual and the original box
for all eventualities.
Eletromedia provides a restricted warranty on the HERTZ products according
to the following terms:
Warranty duration: 2 years.
This warranty is applicable only to HERTZ products sold by HERTZ authorized dealers.
Products found to be defective during the warranty period will be repaired or replaced
with an equivalent product, at Elettromedia’s discretion.
Warranty is void:
1. For damage caused by accidents, abuse, improper operation, water, theft.
2. If after sale service is performed by anyone other than Elettromedia authorized service centers.
3. If serial number has been spoiled, altered or removed from the product.
4. For damages caused by overdriving or amplification excessive distortion due to non-linear
functioning of power supply.
Elettromedia accepts no liabilities for any damage resulting from disregarding the warnings herein.
Warranties for product purchased and used in countries outside Italy are covered by the HERTZ
distributor in that respective country. Warranty length and policies are outlined and enforced
by the distributor.
