3. Holding second rubber gasket, ber gasket and metal backup ring in place, slip mounting ring (6) over sink ange so it seats against

backup ring.

4. With the rubber gasket, ber gasket, backup ring, and mounting ring tight against sink bottom, install the snap ring on the groove of the

sink ange.

5. Tighten three mounting screws (7) up to sink until mounting assembly is seated tightly and evenly against sink.

CLEAN SINK WASTE PIPE

Failure to clean sink waste pipe line may result in waste pipe blockage.

1. Remove trap. (See Figure 5.1)

2. With drain auger, clear away all hardened waste material in horizontal line running from drain trap to main pipe.

IF YOU ARE NOT CONNECTING A DISHWASHER TO DISPOSER, SKIP AHEAD TO INSTRUCTION 7.

DISHWASHER ATTACHMENT AND OVERFLOW CONNECTION

Wastewater from a dishwasher can be plumbed into the disposer through the inlet access on the upper part of the disposer. There is a

plug on the inside of the inlet tube on all models. Once removed, the knockout plug cannot be replaced.

NOTE: If the dishwasher connection is made without removing the plug, the dishwasher may overow. (Connections must comply with

local plumbing codes.)

REMOVE KNOCKOUT PLUG

1. Lay disposed on its side and insert screwdriver into dishwasher inlet so tip rests on outer edge of knockout plug.

2. Tap end of screwdriver handle with hammer until molded plug breaks loose (see Figure 6.1).

3. Remove loose knockout plug from inside disposer. If you have a sink overow, it should be connected to the overow inlet on the

tailpipe (see Figure 6.2).

CONNECT DISPOSER TO MOUNTING ASSEMBLY

CAUTION

PERSONAL INJURY

To avoid personal injury, do not position your head or body under disposer; the unit could fall during installation. Clear any

objects from inside the disposer grind chamber before mounting the disposer to the sink.

1. Position disposer with three mounting tabs (1) aligned in position to slide over mounting tracks (2). (See Figure 7.1)

2. Lift disposer, insert top end (mounting gasket) into mounting assembly, and turn lower mounting ring to right (with wrenchette or

adjustable pliers) until mounting tabs lock over ridges (3) on mounting ring tracks (see Figure 7.2). Make sure all three mounting tabs are

locked over ridges. Disposer will now hang by itself.

3. Run water into sink, then check for leaks.

ATTACH DISCHARGE TUBE TO WASTE DRAIN PIPE

ACAUTION

PROPERTY DAMAGE

Wearing safety glasses is recommended during the installation of the food waste disposer.

Do not use plumber’s putty on any other disposer connection other than on sink ange. Do not use thread sealants or pipe dope. These

may harm disposer and cause property damage.

Regularly inspect disposer and plumbing ttings for water leaks, as water leaks can cause property damage. Manufacturer cannot be

held responsible for property damage as a result of water leaks.

DISCHARGE TUBE INSTALLATION

1. Place metal ange (2) over discharge tube (4). Insert rubber gasket (1) with gasket lip facing the metal ange into discharge tube.

(See Figure 8.1)

2. Secure metal ange and discharge tube to disposer with two 13 mm bolts (3).

3. Rotate disposer so that discharge tube is aligned with drain trap. (To prevent leaks, do not pull or bend discharge tube to drain trap.)

If discharge tube is too short, you can purchase an extension from hardware store. (Disposer must remain in vertical position to prevent

vibration.)

4. Place nut, then ferrule on discharge tube (not supplied) and tighten on drain trap. (If you have a double sink, use separate drain traps

for both sides of sink.)

5. Ensure lower mounting ring is still securely locked over ridges on mounting ange.

6. Place stopper in sink in close position. Fill sink with water, remove stopper and check for leaks.

CONNECT D ISPOSER TO E LECTRICAL SUPPLY

can result in electric shock.

ADANGER

ELECTRICAL SHOCK

• To avoid electrical shock, disconnect power before installing or servicing disposer.

• If you are not thoroughly familiar with electric power, contact qualied electrician to connect disposer to electrical circuit.
