Buffalo TS3400D0804 [43/181] Dismounting drives
![Buffalo TS3400D0804 [43/181] Dismounting drives](/views2/1112647/page43/bg2b.png)
42
Dismounting Drives
If the TeraStation is powered on, dismount drives (internal and external) before unplugging them. You may dismount
external drives with the function button, or any drive from Settings. If the TeraStation is off, then all drives are already
dismounted and may be unplugged safely.
Dismounting with the Function Button
Hold down the function button for 8 seconds. The function button will flash as all external drives are dismounted, which
will take about 30 seconds. When the dismount is finished, the function LED will stop flashing and glow steadily. You
may now unplug any USB drives safely.
Note: After 60 seconds, the function LED will go out and any drives that have not yet been unplugged will be
remounted.
Dismounting from Settings
1 In Settings, click Drives.
2 Click Drives to dismount an internal drive or USB Drives to dismount an external drive.
3 Select the drive to dismount and click Dismount Disk. It will take about 30 seconds for the drive to be dismounted.
4 When the following message is displayed, it is safe to unplug the drive.
