Buffalo TS5400R0804 [171/176] Default settings
![Buffalo TS5400R0804 [171/176] Default settings](/views2/1112693/page171/bgab.png)
170
Recovery I44
Disk1 not found
Recovery from the USB recovery device
was initiated, but the drive 1 was not
detected.
Make sure that Disk 1 is present and fully
inserted in its slot.
Recovery I45
Recovery Failed
Recovery failed. -
RAID ARRAY I46
RMM+Processing
Data migration or conversion (RAID
migration) is in progress.
Do not turn off the TeraStation power.
SYSTEM I47
Don't Power Off
FailOver I48
PushFuncToStart
This TeraStation is ready to become the
failover backup for the main TeraStation.
Hold down the function button on the
front of the target TeraStation until it stops
beeping to accept failover backup status.
FailOver I49
LostMainTarget
The main TeraStation in the failover
configuration cannot be found.
Make sure that the main TeraStation is on,
working, and connected to the network.
FailOver I50
Maintenance mode
Failover maintenance is in progress. Do not turn off the TeraStation power.
FailOver I51
Initializing
Initializing the failover configuration. Do not turn off the TeraStation power.
New Firmware I52
Available
A new firmware version has been
released.
Update the firmware.
BackupTask xx I54
Backup Failure
xxth backup task failed.
Make sure that the backup job is configured
correctly. Make sure that the NAS is on and
not in standby mode. If the backup job still
fails, check the status of NAS, network, and
backup source and destinations.
Recovery I55
RecoveryAuthFail
Authentication during recovery of
settings failed.
Settings can only be restored for the
TeraStation whose settings were originally
saved. To restore settings, insert the USB
memory device, move the Boot Mode
switch on the rear of the TeraStation to the
USB position, and restart the TeraStation. Or,
settings can be restored in Settings with the
TeraStation powered on.
Surveillance I56
Lack of License
There are not enough surveillance
camera server licenses.
Purchase and register an additional license.
Surveillance I57
No free space
There is not enough space to save
additional surveillance video.
Delete or move some of the stored video.
Surveillance I58
Recording Failure
Video not recorded.
Check your settings. Also, use the utilities
provided with your camera to check that
the camera is operating correctly.
Default Settings
Administrator's Name admin
Password password
Shared Folders
"share" (for both Windows and Mac computers). The recycle bin is enabled
on "share" by default.
