Leave the switch in the HDD position during normal operation. To recover settings, insert the recovery USB drive

into a USB 2.0 port, move the boot switch to the USB position, and press the power button.

14 UPS Port

Connect to a UPS.

15 USB 3.0 Port

Compatible Buffalo USB 3.0 hard drives can be connected. USB hubs are not supported.

16 USB 2.0 Port

Compatible Buffalo USB hard drives, USB flash drives, digital cameras, and USB UPS connection can be connected.

USB hubs are not supported.

17 LAN Port 1

Use and Ethernet cable to connect this port to your network.

18 LAN Port 2

This second Ethernet port may be used for network redundancy or backup. You may connect a second TeraStation

directly to this port for backup.

19 Power Connector

Use the included power cable to connect to an UPS, surge protector, or outlet.

Note: A user license sticker is affixed to the power connector. Before removing the sticker, be sure to read the terms

and conditions of the Microsoft Software License contained in the “ms-license” folder of the supplied USB device.

Removing the sticker constitutes agreement to this license.

20 Fan

Do not block the fan.

21 Anti-Theft Security Slot

Use this slot to secure your TeraStation with a cable lock (not included).

22 UID Button

Press the UID button on the front or the back of the unit to cycle the blue LED on and off.

23 Serial Number

This sticker shows the TeraStation’s serial number.

LCD Display

Modes

The LCD display can be cycled through different modes by pressing the display button on the front of the TeraStation.

LCD Message Description
