Chapter 4 Settings
LinkStation User Manual 172
Name Descriptions
Maintenance
Email
Notication
Click Modify
Settings
to change
settings.
Click Send
Test Message
to send a test
email to the
email address
which has
been set.
Notication Select whether using email notication feature or not. Following
message is sent by using Email Notication.
Note: Mail Server displays the list of POP before SMTP (the method to
give the permission to use SMTP server by authenticating at specied
POP server before sending email). If this is set, this feature cannot be
used.
SMTP Server
Address
Enter SMTP Server Address (Mail Server Address).
SMTP Port No. Enter SMTP Port No..
Authentication
Type
Select Authentication Type from POP before SMTP, LOGIN(SMTP-AUTH),
and CRAM-MD5(SMTP-AUTH/CRAM-MD5).
POP3 Server
Address
Enter the POP3 Server Address (Email server address).
POP3 Port No. Enter POP Port No.
SSL/TLS When LOGIN(SMTP-AUTH) and CRAM-MD5(SMTP-AUTH/CRAM-MD5)
are selected for Authentication Type, specify either using SSL or TLS.
Username Enter a username that will be used for authentication.
Password Enter the password used to access with above user name.
Subject Specify the subject of the email to be sent. Use only one-byte
characters, not two-byte characters.
Recipient(s) Enter the email address of the receiver, and click Add. You can register
up to 5 email addresses as receivers.
Report Select the contents to send in the email notication.
HDD Status Report:
Send the status other hard drive of the LinkStation on the specied
time on HDD Status Sending Time.
Fan Failure:
Sent if a problem on the fan of the LinkStation.
Disk Error:
Sent when an error occurs on the drive.
Backup Complete:
Sent if the backup of the LinkStation is completed.
