15
Specifications
CPU
Supports Intel® Core™ 14th/ 13th/ 12th Gen Processors,
Intel® Pentium® Gold and Celeron® Processors*
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B760 Chipset
Memory
4x DDR4 memory slots, support up to 128GB*
Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
Max. overclocking frequency:
1DPC 1R Max speed up to 5333+ MHz
1DPC 2R Max speed up to 4800+ MHz
2DPC 1R Max speed up to 4400+ MHz
2DPC 2R Max speed up to 4000+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
2x PCIe x16 slots
PCI_E1 slot (From CPU)
Supports PCIe 5.0 x16
PCI_E3 slot (From B760 chipset)
Supports PCIe 4.0 x4
1x PCIe x1 slot
PCI_E2 slot (From B760 chipset)
Supports PCIe 3.0 x1
Onboard Graphics
1x HDMI™ 2.1 port with HDR, supports a maximum
resolution of 4K 60Hz*/**
1x DisplayPort 1.4 with HBR3, supports a maximum
resolution of 8K 60Hz*/** (For MAG B760M MORTAR MAX
WIFI DDR4
1x DisplayPort 1.4, supports a maximum resolution of 4K
60Hz*/** (For MAG B760M MORTAR WIFI DDR4 & MAG
B760M MORTAR DDR4
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
Continued on next column
