Hardware Installation - 12 -
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is
installed, the actual memory size displayed will be less than 4 GB.
(Note 2) To enable 7.1-channel audio, you have to use an HD front panel audio module and enable the
multi-channel audio feature through the audio driver.
(Note 3) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to
install it in the PCIEX16 slot
(Note 4) When the PCIEX1 slot is populated with an expansion card, the PCIEX4 slot will operate at up to
x1 mode.
(Note 5) The PCIEX16 slot operates at up to x4 mode when ATI CrossFireX
™
is enabled.
(Note 6) Whether the CPU/system fan speed control function is supported will depend on the CPU/system
cooler you install.
(Note 7) Available functions in EasyTune may differ by motherboard model.
Unique Features
Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
(Note 7)
Support for Dynamic Energy Saver
™
2
Support for Smart TPM
j
Support for Smart 6
™
Support for Auto Green
Support for Q-Share
Bundled Software
Norton Internet Security (OEM version)
Operating System
Support for Microsoft
®
Windows
®
7/Vista/XP
Form Factor
ATX Form Factor; 30.5cm x 19.0cm
j
Only for GA-P55-UD3L-TPM.
