- 13 - Hardware Installation

DisplayPort

DisplayPort is one of the new generation interface technologies that delivers high quality digital imaging

and audio, supporting bi-directional audio transmition. DisplayPort can support both DPCP and HDCP

content protection mechanisms. Connect the audio/video device that supports DisplayPort to this port.

The DisplayPort Technology can support a maximum resolution of 2560x1600p but the actual resolu-

tions supported depend on the monitor being used.

When removing the cable connected to a back panel connector, rst remove the cable from your •

After installing the DisplayPort device, make sure the default device for sound playback is the Dis-

playPort device. (The item name may differ from operating system. For example, in Windows Vista,

go to Start>Control Panel>Sound>Playback and set the DisplayPort device as the default play-

back device. Refer to the HDMI settings information on the previous page for the conguration

dialog box.)

Center/Subwoofer Speaker Out Jack (Orange)

Use this audio jack to connect center/subwoofer speakers in a 5.1/7.1-channel audio conguration.

Rear Speaker Out Jack (Black)

Use this audio jack to connect rear speakers in a 4/5.1/7.1-channel audio conguration.

Side Speaker Out Jack (Gray)

Mic In Jack (Pink)

The default Mic in jack. Microphones must be connected to this jack.

DualMonitorCongurationsfortheOnboardGraphics:

This motherboard provides four video output ports: D-Sub, DVI-D, HDMI, and DisplayPort.

Dual monitor congurations are supported in operating system environment only, but not during the

BIOS Setup or POST process.

In addition to the default speakers settings, the ~ audio jacks can be recongured to perform

different functions via the audio software. Only microphones still MUST be connected to the de-

fault Mic in jack ( ).

Connection/Activity LED:
