- 23 - BIOS Setup
To access the BIOS Setup program, press the <Delete> or <F2> key during the POST when the power is
turned on.
Chapter 2 BIOS Setup
Because BIOS ashing is potentially risky, if you do not encounter problems using the current •
version of BIOS, it is recommended that you not ash the BIOS. To ash the BIOS, do it with
caution. Inadequate BIOS ashing may result in system malfunction.
It is recommended that you not alter the default settings (unless you need to) to prevent system •
instability or other unexpected results. Inadequately altering the settings may result in system's
failure to boot. If this occurs, try to clear the CMOS values and reset the board to default values.
(Refer to the introductions of the battery/clearing CMOS jumper in Chapter 1 for how to clear the
CMOS values.)
2-1 The POST screen
During the POST, look for a message which says "Press <DEL> or <F2> to enter setup." Press <DEL> or
<F2> to enter the BIOS setup utility.
2-2 The Main Menu
Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use ar-
row keys to move among the items and press <Enter> to accept or enter a sub-menu.
(SampleBIOSVersion:F3)
Version 2.10. 1208. Copyright (C) 2010 American Megatrends. Inc.
BIOS Date: 03/30/2011 11:09:33 Ver:1A0QI
Press <DEL> or <F2> to enter setup.
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
BIOS Information
Project Name Q67M-D2H-B3
Project Version F3
Memory Information
Total Memory 1024 MB (DDR3 1333)
LAN MAC Information
LAN MAC Address 888888888788
System Language [English]
System Date [Wed 30/03/2011]
System Time [13:46:38]
: Select Screen
: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
This section provides information on the BIOS information, Memory information, and LAN MAC information.
System Language
Chooses the BIOS default language.
