- 25 - BIOS Setup
Wake system with Dynamic Time
Enables or disables system wake on alarm event. When enabled, the system will wake on the current
time+Increase minute(s).
}
Trusted Computing
TPM SUPPORT
Enables or disables TPM support. O.S. will not show TPM. Reset of platform is required.
}
CPUConguration
This screen provides information on CPU frequencies/parameters.
}
SATAConguration
Enables or disables the SATA function for the SATA Ports.
}
Intel IGD SWSCI OpRegion
DVMT Mode Select
Selects DVMT Mode used by Internal Graphics Device.
DVMT/FIXED Memory
Selects DVMT/FIXED Mode Memory size used by Internal Graphics Device.
}
IntelTXT(LT)Conguration
Intel TXT support only can be enabled/disabled if SMX is enabled. VT and VT-d Support must also be
enabled prior to TXT.
}
USBConguration
Legacy USB Support
Allows USB devices to be used in MS-DOS.
EHCI Hand-off
This is a workaround for 0Ses without EHCI hand-off support. The EHCI ownership change should be
claimed by EHCI driver.
Port 60/64 Emulation
Enables I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard
legacy support for non-USB aware 0Ses.
}
InfoReportConguration
Post Report
Enables or disables Post Report Support.
Delay Time
Post Report Wait TIme:0~10 secinds.
Info Error Message
Enables or disables Info Error Message Support.
}
SuperIOConguration
SerialPort0/1Conguration
Enables or disables the rst/second serial port and species its base I/O address and corresponding
interrupt.
ParallelPortConguration
Selects an operating mode for the onboard parallel (LPT) port.
AC BACK
Determines the state of the system after the return of power from an AC power loss.
}
H/W Monitor
This section provides information on the PC Health Status.
