BIOS Setup - 38 -
>>>>> Channel A/B Standard Timing Control
CAS Latency Time
Options are: Auto (default), 5~15.
tRCD
Options are: Auto (default), 1~15.
tRP
Options are: Auto (default), 1~15.
tRAS
Options are: Auto (default), 1~40.
>>>>> Channel A/B Advanced Timing Control
tRC
Options are: Auto (default), 1~63.
tRRD
Options are: Auto (default), 1~15.
tWTR
Options are: Auto (default), 1~15.
tWR
Options are: Auto (default), 1~16.
tWTP
Options are: Auto (default), 1~31.
tWL
Options are: Auto (default), 1~12
tRFC
Options are: Auto (default), 1~255.
tRTP
Options are: Auto (default), 1~15.
>>>>> Channel A/B Timing Settings
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Channel A Timing Settings
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
>>>>> Channel A Standard Timing Control
x CAS Latency Time 8 Auto
x tRCD 8 Auto
x tRP 8 Auto
x tRAS 20 Auto
>>>>> Channel A Advanced Timing Control
x tRC 27 Auto
x tRRD 4 Auto
x tWTR 4 Auto
x tWR 8 Auto
x tWTP 19 Auto
x tWL 7 Auto
x tRFC 60 Auto
x tRTP 4 Auto
x tFAW 16 Auto
x Command Rate (CMD) 1 Auto
>>>>> Channel A Misc Timing Control
x IO Latency 1 Auto
x Round Trip Latency 29 Auto
