- 7 -
GA-H67N-USB3-B3 Motherboard Layout
(Note 1) The LAN chip is located on the back of the motherboard.
(Note 2) The BIOS ash ROM is located below the latch on the PCIEX16 slot.
R_SPDIF
VGA_HDMI
CPU_FAN
LGA1155
ATX
GA-H67N-USB3-B3
F_AUDIO
AUDIO
B_BIOS
(Note 2)
M_BIOS
PCIEX16
DDR3_1
DDR3_2
BAT
ATX_12V
Intel
®
H67
USB_HDMI
USB30_LAN
USB_ESATA
CODEC
SATA2_3
SATA3_1
SATA2_2
SATA3_0
Renesas
D720200
iTE IT8728F
CLR_CMOS
F_PANEL
F_USB2
F_USB1
(NOTE 3)
SYS_FAN
SPDIF_O
PHASE LED
Realtek
RTL8111E
(Note 1)
