Develop ineo 4750 [15/70] Option configuration

ineo 4050/4750 2-5

2.1 About this machine

2.1.2 Option configuration

dReference

For details on how to register i-Option license kits, refer to [User's Guide Advanced Functions].

NOTICE

When removing and installing an optional device, turn this machine off, then disconnect the power plug from

the outlet.

No. Name Description

1 Keypad KP-P01 Located on the side of the Control Panel.

Allows you to enter numbers by using the Hardware Keypad.

2 Authentication Unit

AU-201

Performs user authentication by scanning information recorded on

the IC card.

3 Finisher FS-P02 Staples the printed sheets.

For staples, use Staple Kit SK-501.

4 Paper Feed Unit

PF-P11

Allows you to load up to 250 sheets of paper.

There are three slots in which the Paper Feed Unit can be installed.

5 Paper Feed Unit

PF-P12

Allows you to load up to 550 sheets of paper.

There are three slots in which the Paper Feed Unit can be installed.

6 DESK DK-P02 Used to install this machine on the floor.

This component may not be able to be used depending on the region

the machine is used in.

The following optional components are built into this machine and are not shown in the figure above.

7 Fax Kit FK-512 Used to operate this machine as a fax machine.

8 Mount Kit MK-P03 This unit is required to install the Fax Kit.

9Local Interface Kit

EK-P04

Used to add an RS-232C port.

10 i-Option LK-106 Used to add a bar code font, which is one of special fonts.

11 i-Option LK-107 Used to add a unicode font, which is one of special fonts.

12 i-Option LK-108 Used to add an OCR font, which is one of special fonts.

13 i-Option LK-111 Supports the ThinPrint function, which is one of a number of ad-

vanced functions.

5 4
