Develop ineo 4750 [46/70] Checking the network settings
![Develop ineo 4750 [46/70] Checking the network settings](/views2/1116642/page46/bg2e.png)
5-4 ineo 4050/4750
Using the print function (Windows environment)
5
5.1
5.1.2 Preparation for printing (network connection)
Checking a LAN cable for connection
Check that a LAN cable is connected to the LAN port of this machine.
For details on the cable connection port, refer to page 2-4.
Checking the network settings
Print out the Configuration Page, then check that an IP address is assigned to this machine.
To print out the Configuration Page, select [Utility] - [User Settings] - [Printer Settings] - [Print Reports] - [Con-
figuration Page].
dReference
If no IP address is displayed, you need to set up the network. For details, refer to page 4-3.
Installing the printer driver
Use the installer to install the printer driver on your computer.
0 Administrator privileges are required to perform this task.
0 Use the Driver & Utilities CD/DVD-ROM.
1 Insert the printer driver CD/DVD-ROM into the CD/DVD-ROM drive of the computer.
% Make sure that the installer starts, then proceed to Step 2.
% If the installer does not start, open the printer driver folder on the CD/DVD-ROM, double-click [Set-
up.exe], then go to Step 3.
% If the [User Account Control] window appears, click [Continue] or [Yes].
2 Click [Printer/FAX].
3 Read the license agreement, then click [AGREE].
4 Check the contents of the [Readme] window, then click [Next].
5 Select [Install printers/MFPs], then click [Next].
Connected printers are detected.
% For Windows Vista/7/8/8.1/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2, you can se-
lect [Preference for IPv4] or [Preference for IPv6]. The address has the preference when detected in
both IPv4 and IPv6.
6 Select this machine, then click [Next].
% If this machine is not detected, restart it.
% You do not need to change the printing method from [Normal Printing] (Port 9100) unless otherwise
specified by the administrator. This guide describes how to configure the [Normal Printing] (Port
9100) setting.
% As the printing method, you can select [Normal Printing], [Internet Printing] (IPP), or [Secure Printing]
(IPPS). For details on the printing method, refer to [User's Guide Print].
% Among the connected printers, only the target model is automatically detected and displayed. If
multiple target models are displayed, check the IP addresses.
% If the connection to this machine cannot be recognized, it is not displayed in the list. In such a case,
select [Specify the Printer/MFP Except for the Above. Select (IP Address, Host Name...)], then man-
ually specify the IP address and host name of this machine.
7 Select the check box of the printer driver you want to install, then click [Next].
% For features of each printer driver, refer to page 5-3.
8 Check the components to be installed, then click [Install].
