Thermaltake LANBOX Lite [5/12] 2 2 5 5 accessory drive installation

There are five springs in the front panel, push to release it.

Push and release the five springs of front panel.

2-2-2 5.25" accessory drive installation

When installing a 5.25" accessory drive on the top bay,

please install the metal adaptor first as shown. Screw in the

5.25" accessory drive on the opposing side of the No.5 hole.

Screw the top optical drive bay as shown.

Please make sure the 5.25"

accessory drive is flush with

the front panel.

After loosing the spring of

front panel, pull out it as

arrow shows.

Remove the 5.25" bay cover as arrow shows.

Unscrew the 5.25" bay

cover screw as shown.
