Thermaltake LANBOX Lite [6/12] Hdd installation

HDD installation

2-3

Unscrew the screw shown to remove the HDD rack.

Slide over the HDD rack

as shown to remove.

Secure HDDs using screws when installing in the HDD rack.

The HDD rack.

A HDD can be installed

on the side by securing

4 screws.

Screw in both sides of

the HDD.

2-3-1 Install HDD on the HDD rack 2-3-2 Install HDD on the side of optical drive tray

Unscrew the 2 screws as shown to slide back the

optical drive tray.

Pull back, then pull up to remove the optical drive tray.
