Milwaukee M18 BDD [10/37] English english 19

Milwaukee M18 BDD [10/37] English english 19
18 19
M18 BDD M18 BPD
..................... 4479 41 01... ................4479 46 01...
..................... 4435 31 01... ................4435 01 01...
...000001-999999 ...000001-999999
...........................13 mm ..........................13 mm
...........................38 mm ..........................38 mm
............................... ................................16 mm
.............................7 mm ............................7 mm
......................0-450 min
-1
....................0-450 min
-1
....................0-1800 min
-1
..................0-1800 min
-1
..............................- min
-1
..................0-7200 min
-1
..............................- min
-1
................0-28800 min
-1
...........................50 Nm ...........................50 Nm
...........................60 Nm ...........................60 Nm
...........................18 V ..............................18 V
.....................1,5-13 mm ....................1,5-13 mm
..........................1,8 kg ............................1,9 kg
..........................2,0 kg ............................2,1 kg
........................84,7 dB (A) ...................84,7 dB (A)
........................95,7 dB (A) ...................95,7 dB (A)
...........................13 m/s
2
..........................13 m/s
2
..........................1,5 m/s
2
.........................1,5 m/s
2
........................0,95 m/s
2
.......................0,95 m/s
2
..........................1,5 m/s
2
.........................1,5 m/s
2
........................0,66 m/s
2
.......................0,66 m/s
2
..........................1,5 m/s
2
.........................1,5 m/s
2
ENGLISH
TECHNICAL DATA Cordless percussion drill/driver
Production code.......................................................................
..............................................................................................
Drilling capacity in steel ...........................................................
Drilling capacity in wood ..........................................................
Drilling capacity in brick and tile ..............................................
Wood screws (without pre-drilling) ..........................................
No-load speed 1st gear ...........................................................
No-load speed 2nd gear ..........................................................
Impact rate 1st gear.................................................................
Impact rate 2nd gear ...............................................................
Torque with battery *1 (1.5 Ah / 2.0 Ah) ...................................
Torque with battery *1 (3.0 Ah / 4.0 Ah) ...................................
Battery voltage.........................................................................
Drill chuck range ......................................................................
Weight according EPTA-Procedure 01/2003 (1.5 Ah / 2.0 Ah)
Weight according EPTA-Procedure 01/2003 (3.0 Ah / 4.0 Ah)
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3 dB(A)) .......................................
Sound power level (K = 3 dB(A)) ............................................
Always wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745.
Vibration emission value a
h
Impact drilling into concrete ..................................................
Uncertainty K= ......................................................................
Drilling into metal ..................................................................
Uncertainty K= ......................................................................
Screw driving without impact ................................................
Uncertainty K= ......................................................................
*1 Measured according to Milwaukee standard N 877318
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
DRILL DRIVER SAFETY WARNINGS
Wear ear protectors when impact drilling. Exposure to
noise can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of
control can cause personal injury.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring. Cutting accessory contacting
a "live" wire may make exposed metal parts of the power
tool "live" and could give the operator an electric shock.
Hold power tool by insulated gripping surfaces, when
performing an operation where the fastener may
contact hidden wiring. Fasteners contacting a "live" wire
may make exposed metal parts of the power tool "live" and
could give the operator an electric shock.
Sawdust and splinters must not be removed while the
machine is running.
When working in walls ceiling, or fl oor, take care to avoid
electric cables and gas or waterpipes.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household
refuse or by burning them. Milwaukee Distributors offer to
retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only System C18 chargers for charging System C18
battery packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under
extreme load or extreme temperatures. In case of contact
with battery acid wash it off immediately with soap and
water. In case of eye contact rinse thoroughly for at least 10
minutes and immediately seek medical attention.
SPECIFIED CONDITIONS OF USE
The electronic battery percussion drill/screwdriver may be
used for drilling, percussion drilling, as well as screwdriving
for independent use away from mains supply.
Do not use this product in any other way as stated for
normal use.
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may signifi cantly increase
the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
ENGLISH
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under “Technical Data” fulfi lls all the relevant
regulations and the directives 2011/65/EU (RoHs),
2006/42/EC, 2004/108/EC and the following harmonized
standards have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-1:2010
EN 60745-2-2:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
Winnenden, 2013-06-12
Alexander Krug
Managing Director
Authorized to compile the technical fi le.
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have not
been used for some time should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
For an optimum life-time, the battery packs have to be fully
charged, after used.
To obtain the longest possible battery life remove the battery
pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
BATTERY PACK PROTECTION
In extremely high torque, binding, stalling and short circuit
situations that cause high current draw, the tool will vibrate
for about 2 seconds and then the tool will turn OFF.
To reset, release the trigger.
Under extreme circumstances, the internal temperatur of the
battery could become to high. If this happens, the battery
will shut down.
Place the battery on the charger to charge and reset it.
INTENANCE
Use only Milwaukee accessories and spare parts. Should
components need to be replaced which have not been
described, please contact one of our Milwaukee service
agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the machine type printed as well as the six-digit
No. on the label and order the drawing at your local service
agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully before
starting the machine.
Remove the battery pack before starting any
work on the machine.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste
electrical and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their
life must be collected separately and returned to
an environmentally compatible recycling facility.
