Kranzle 2+2 [7/20] Servicing

Servicing

Whentherollersareworn,thesweepercan

beplacedapprox.1-1,5mmlowerbyremo-

vingthetwowashersno.13(seepage10).

Important:



Easyreplacementofbrushrollers:

1)Putthemachineuprightonthejointsof

thefolded-inpushbarandtheframe.

2)Turnthebrushrolleruntilthetwoscrews

no.34ontheleftandrightsiderespectively

arevisible(seepage12)andremovethese

4screws.

3)Turnthebrushrollersanotherhalf-turn

andremovethembypullingthemout.

4)Fitthenewrollersinthereverseorder.

One washer no. 13  must

always be kept under the

screwholetoavoiddamaging

totheplasticframe
